Запчасти Doosan Daewoo STEERING PIPING BODY PARTS

-

4400-2055

STEERING PIPING

SC: D

-2шт.

1

4182-1794B

PIPE

desc: CONDUITE

1шт.

2

4182-1795B

PIPE

desc: CONDUITE

1шт.

3

2184-1036D128

HOSE PF1/2-1030L

desc: TUYAU FLEXIBLE

2шт.

4

2184-1054D84

HOSE PF1/2-550L

desc: TUYAU FLEXIBLE

2шт.

5

2184-1054D83

HOSE PF1/2-500L

desc: TUYAU FLEXIBLE

2шт.

7

2124-1025D10

CLAMP;PIPE

desc: ATTACHE DE TUBE

4шт.

8

4627-1663A

PLATE

desc: PLAQUE

2шт.

10

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD

5шт.

12

S0558253

BOLT M10X1.5X35

desc: BOULON M10X1.5X35

4шт.

13

S5010613

WASHER;PLAIN M10

desc: RONDELLE

8шт.

14

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

6шт.

18

S0558653

BOLT M10X1.5X55

desc: BOULON A 6 PANS

2шт.

19

S4012633

NUT M10X1.5

desc: ECROU M10X1.5

2шт.

21

S8000181

O-RING P18

desc: JOINT TORIQUE

6шт.

22

2181-1126D33

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

1шт.
