Запчасти Doosan Daewoo AXLE & DRIVE SHAFT BODY PARTS

-

211-00037

AXLE & DRIVE SHAFT ASS'Y

SC: D

-2шт.

1

211-00023

AXLE;FRONT

SERIAL: 1001-1026

1шт.

1

211-00023A

AXLE;FRONT

SERIAL: 1027

1шт.

2

211-00041

AXLE;REAR

SERIAL: 1001-1026

1шт.

2

211-00041A

AXLE;REAR

SERIAL: 1027

1шт.

3

260-00022A

DRIVE SHAFT;FRONT

desc: ARBRE

1шт.

3A

1100-5C

U-JOINT

desc: . JOINT-U

1шт.

3B

700-UCP211

CENTER BEARING

desc: . PALIER

1шт.

4

260-00023A

DRIVE SHAFT;CENTER

desc: ARBRE

1шт.

4A

1100-5C

U-JOINT

desc: . JOINT-U

2шт.

5

260-00024A

DRIVE SHAFT;REAR

desc: ARBRE

1шт.

5A

1100-5C

U-JOINT

desc: . JOINT-U

2шт.

6

195-00665

SUPPORT;AXLE

SERIAL: 1001-1023

2шт.

6

195-00665A

SUPPORT;AXLE

SERIAL: 1024

2шт.

6A

4110-1410

BUSHING

desc: . COUSSINET

1шт.

8

2181-1919D9

ADAPTER PT1/8-M14X1.5

desc: RACCORD

2шт.

9

S8011400

O-RING

desc: JOINT TORIQUE

2шт.

11

222-00016

PLATE

desc: PLAQUE

2шт.

12

4120-4054

BOLT M22X2.5X290

desc: BOULON A 6 PANS

8шт.

13

S4013233

NUT M22X2.5

desc: ECROU HEXAGONAL

16шт.

14

4114-4117

WASHER;HARD

desc: RONDELLE

16шт.

15

4114-1930

WASHER;THRUST

desc: RONDELLE

2шт.

16

S0571261

BOLT M20X2.5X120

desc: BOULON A 6 PANS

8шт.

17

S4013133

NUT M20X2.5

desc: ECROU

16шт.

18

4114-4116

WASHER;HARD

desc: RONDELLE

16шт.

19

S0565161

BOLT M16X2.0X45

desc: BOULON A 6 PANS

2шт.

20

S5102901

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

21

S5010913

WASHER;PLAIN M16

desc: RONDELLE PLATE

2шт.

22

S0508453

BOLT M8X1.25X12

desc: BOULON M8X1.25X12

2шт.

23

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

24

4114-1701

WASHER;SPRING

desc: RONDELLE ELASTIQUE 3/8"

20шт.

25

S6710041

NIPPLE;GREASE

desc: GRAISSEUR

2шт.

26

4120-4016

BOLT

desc: BOULON A 6 PANS

20шт.

27

4276-9017

TIRE 17.5X25(L2)

desc: PNEU INTERIEUR

4шт.

28

278-00036

RIM 14.0X25

desc: JANTE

4шт.

29

2181-1918D6

ELBOW

desc: COUDE

2шт.

30

140-00340

PIPE

desc: CONDUITE

1шт.

31

140-00341

PIPE

desc: CONDUITE

1шт.

32

4124-4047

CLIP;PIPE

desc: CLIP DE FIXATION

1шт.

33

2124-1248

CLIP;PIPE

desc: CLIP DE FIXATION

1шт.

34

123-00264

PIN

SERIAL: 1024

2шт.
