Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

101

65.03101-6071A

CYLINDER HEAD ASS'Y

SERIAL: 040924

1шт.

101

65.03101-6071B

CYLINDER HEAD ASS'Y

SERIAL: 040925

1шт.

102

65.03101-1043C

HEAD;CYLINDER

SC: D

1шт.

104

65.03201-1013

GUIDE;VALVE

SERIAL: 040924

12шт.

104

65.03201-1013A

GUIDE;VALVE

SERIAL: 040925

12шт.

105

65.03203-1054

SEAT;EXHAUST VALVE

SC: B

6шт.

106

65.03203-1053

SEAT;INLET VALVE

SC: B

6шт.

107

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

108

65.90302-0030

PLUG;CORE(EXHAUST MAIN)

desc: . BOUCHON

6шт.

109

65.90302-0019B

PLUG;CORE

desc: . BOUCHON

11шт.

110

65.90302-0045

PLUG;CORE NW 20

desc: . BOUCHON

3шт.

111

65.90302-0027

PLUG;CORE NW 12

desc: . BOUCHON

6шт.

112

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

113

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

114

65.91710-0004

RING;STOPPER

desc: BAGUE D'ARRET

2шт.

116

06.06225-0706

BOLT;STUD

desc: GOUJON

3шт.

117

06.06125-8717

BOLT;STUD

desc: GOUJON

11шт.

118

65.90201-0016

BOLT;STUD

desc: GOUJON

1шт.

120

65.90020-0294

BOLT;CYLINDER HEAD

SERIAL: 060508

18шт.

120

65.90021-0002

BOLT;CYLINDER HEAD

SERIAL: 060509

18шт.

121

65.90020-0295

BOLT;CYLINDER HEAD

SERIAL: 060508

6шт.

121

65.90021-0003

BOLT;CYLINDER HEAD

SERIAL: 060509

6шт.

122

65.90020-0296

BOLT;CYLINDER HEAD

SERIAL: 060508

2шт.

122

65.90021-0004

BOLT;CYLINDER HEAD

SERIAL: 060509

2шт.

124

65.19202-5005

HOOK;LIFTING

desc: CROCHET

1шт.

125

65.03901-0055

GASKET;CYLINDER HEAD

desc: JOINT DE CULASSE

1шт.

127

65.26810-0007

CONNECTOR

desc: RONDELLE D'ETANCHEITE

1шт.

128

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

129

06.01733-4409

BOLT;HEX. M14X1.5X25

desc: BOULON A 6 PANS

1шт.

130

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

131

06.01733-4208

BOLT;HEX. M10X1.25X22

desc: BOULON A 6 PANS

1шт.

132

65.26803-7004B

PLUG;GROW

SERIAL: 040115

6шт.

132

65.26803-7004C

PLUG;GROW

SERIAL: 060317

6шт.

132

65.26803-7004D

PLUG;GROW

SERIAL: 060318

6шт.

133

65.19202-0005

HOOK;LIFTING

desc: CROCHET

1шт.

134

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: BOULON A 6 PANS

2шт.

139

65.04902-0011A

SEAL;VALVE STEM

SERIAL: 040616

12шт.

139

65.04902-0015

SEAL;VALVE STEM

SERIAL: 040617

12шт.

200

65.03401-6065

COVER;CYLINDER HEAD

SERIAL: 060206

1шт.

200

65.03401-6098

COVER;CYLINDER HEAD

SERIAL: 060207

1шт.

201

65.03401-6095

COVER;CYLINDER HEAD

desc: . COUVERCLE

1шт.

202

65.03435-0001

COVER (FOR C/H C)

desc: . COUVERCLE

1шт.

203

06.04190-8806

BOLT

desc: . BOUCHON DE REMPLISSAGE D'HUILE

6шт.

204

06.16731-2104

WASHER;SPRING

desc: . BOUCHON DE REMPLISSAGE D'HUILE

6шт.

205

65.03905-0002B

PACKING;CYLINDER HEAD COVER

desc: . RONDELLE D'ETANCHEITE

1шт.

206

65.90501-0028

NUT;CYLINDER HEAD COVER

desc: . ECROU

4шт.

207

65.90701-0202

WASHER;PLATE

desc: . RONDELLE

4шт.

208

65.03905-0023A

GASKET;CYL. HEAD COVER

desc: . ECROU

4шт.

209

65.03903-0001

PACKING(FOR COVER)

desc: . BOUCHON DE REMPLISSAGE D'HUILE

1шт.

220

65.01810-5007

CAP;OIL FILLER

SERIAL: 051230

1шт.

220

65.01810-5011

CAP;OIL FILLER

SERIAL: 051231

1шт.
