Запчасти Doosan Daewoo REMOTE PRESSURE CHECK PIPING BODY PARTS

-

400-00435

REMOTE PRESSURE CHECK PIPING

SC: D

-2шт.

1

4423-1451

BLOCK

desc: BLOC

1шт.

2

S0559153

BOLT M10X1.5X80

desc: BOULON A 6 PANS

2шт.

3

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

4

120-00002

SCREW;COUPLING

desc: VIS

4шт.

6

2184-1026D186

HOSE PF1/4-570L

desc: TUYAU FLEXIBLE

1шт.

7

DS2055678

HOSE PF1/4-1250L

desc: TUYAU FLEXIBLE

1шт.

8

S8000111

O-RING

desc: JOINT TORIQUE

4шт.

9

2181-1126D14

ADAPTER PFO1/4-PF1/4

desc: RACCORD ADAPTATEUR

4шт.

10

2184-1026D139

HOSE PF1/4-900L

desc: TUYAU FLEXIBLE

2шт.

11

181-00372A

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

12

180-00408

O-RING

desc: JOINT TORIQUE

1шт.
