Запчасти Doosan Daewoo REMOTE PRESSURE CHECK PIPING BODY PARTS

-

4400-2075

REMOTE PRESSURE CHECK PIPING

SERIAL: 1001-1020

-2шт.

1

4423-1451

BLOCK

desc: BLOC

1шт.

2

S0559153

BOLT M10X1.5X80

desc: BOULON A 6 PANS

2шт.

3

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

2шт.

4

120-00002

SCREW;COUPLING

desc: VIS

4шт.

5

2184-1036D277

HOSE PF1/4-750L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1026D186

HOSE PF1/4-570L

desc: TUYAU FLEXIBLE

1шт.

7

2184-1036D166

HOSE PF1/4-1400L

desc: TUYAU FLEXIBLE

1шт.

8

2184-1036D371

HOSE PF1/4-850L

desc: TUYAU FLEXIBLE

1шт.

9

S8000111

O-RING P11

desc: JOINT TORIQUE

5шт.

10

2181-1126D14

ADAPTER PFO1/4-PF1/4

desc: RACCORD ADAPTATEUR

5шт.
