Запчасти Doosan Daewoo RADIATOR MOUNTING BODY PARTS

-

4202-1025

RADIATOR MOUNTING

SERIAL: 1001-1020

-2шт.

1

4161-9074

RUBBER;MOUNTING

desc: MANCHON CAOUTCHOUC

4шт.

2

2114-1058D71

WASHER

desc: RONDELLE

8шт.

3

4197-2385C

BRACKET;RADIATOR

desc: SUPPORT

1шт.

4

4197-2384

BRACKET;RESERVE TANK

desc: SUPPORT

1шт.

5

4124-1674A

CLAMP;RESERVE TANK

desc: CLIP DE FIXATION

1шт.

6

2470-9010

RESERVE TANK

desc: RESERVOIR

1шт.

7

4185-1764

HOSE

desc: TUYAU

1шт.

8

S0511853

BOLT M10X1.5X20

SERIAL: 1001-1010

4шт.

8

S0512053

BOLT M10X1.5X25

SERIAL: 1011

4шт.

9

S5102603

WAHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

10

S5010613

WASHER;PLAIN M10

desc: RONDELLE

4шт.

11

S8450006

CLAMP;HOSE

desc: COLLIER

3шт.

12

2185-9072

HOSE 1350L

desc: TUYAU FLEXIBLE

1шт.

13

S0515453

BOLT M12X1.75X40

desc: BOULON

4шт.

14

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

4шт.

15

S5010713

WASHER;PLAIN M12

desc: RONDELLE M12

4шт.

16

4202-9075

RADIATOR

desc: RADIATEUR

1шт.

17

4627-1615A

COVER

desc: COUVERCLE

1шт.

18

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

4шт.

19

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

8шт.

20

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

8шт.

21

4202-9084A

OIL COOLER ASS'Y

desc: ENSEMBLE REFROIDISSEUR D'HUILE

1шт.

22

4197-2693B

BRACKET;L.H

desc: SUPPORT

1шт.

23

4197-2694B

BRACKET;R.H

desc: SUPPORT

1шт.

24

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

4шт.

25

2124-1084D2

CLIP;BAND

desc: ATTACHE

1шт.

26

S4012733

NUT M12X1.75

SERIAL: 1011

4шт.
