Запчасти Doosan Daewoo PILOT PIPING-2 SPOOL STD BODY PARTS

-

4400-2064

PILOT PIPING-2 SPOOL(STD)

SERIAL: 1001-1020

-2шт.

1

4420-1263

VALVE;REMOCON

desc: CONTROLEUR

1шт.

2

S2204861

BOLT;SOCKET M6X1.0X20

desc: BOULON A 6 PANS CREUX

4шт.

3

S5110301

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

4

2181-1917D55

ADAPTER PF1/4-PF3/8

desc: RACCORD ADAPTATEUR

6шт.

5

S8180221

RING;SEAL

desc: RONDELLE D'ETANCHEITE

6шт.

6

2184-1026D236

HOSE PF3/8-1100L

desc: TUYAU FLEXIBLE

2шт.

7

2184-1026D169

HOSE PF3/8-1150L

desc: TUYAU FLEXIBLE

3шт.

8

4197-2473A

BRACKET

SERIAL: 1001-1012

1шт.

8

4197-2473B

BRACKET

SERIAL: 1013

1шт.

9

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

12шт.

12

2181-2718

ADAPTER PF3/8-PF3/8

desc: RACCORD ADAPTATEUR

10шт.

13

2184-1036D256

HOSE PF3/8-650L

desc: TUYAU FLEXIBLE

2шт.

14

2184-1036D2

HOSE PF3/8-600L

desc: TUYAU FLEXIBLE

4шт.

15

2181-1702D3

ELBOW;S PF1/4-PF3/8

desc: RACCORD

2шт.

16

2181-1126D85

ADAPTER;S PF1/4-PF3/8

desc: RACCORD

2шт.

17

S8000111

O-RING P11

desc: JOINT TORIQUE

5шт.

19

2184-1026D66

HOSE PF3/8-600L

desc: TUYAU FLEXIBLE

1шт.

20

2184-1036D114

HOSE PF3/8-960L

desc: TUYAU FLEXIBLE

1шт.

21

2184-1026D163

HOSE PF3/8-950L

desc: TUYAU FLEXIBLE

1шт.

22

4420-9581

VALVE;PILOT

desc: VANNE PILOTE

1шт.

23

4197-2686A

BRACKET

desc: SUPPORT

1шт.

24

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

6шт.

26

S8000181

O-RING P18

desc: JOINT TORIQUE

5шт.

27

2460-9057

ACCUMULATOR;PILOT

desc: RESERVOIR

1шт.

28

4474-9061

FILTER;IN LINE

desc: FILTRE

1шт.

29

4197-2512

BRACKET

desc: SUPPORT

1шт.

30

2181-1702D5

ELBOW PF3/8-PF3/8

desc: COUDE EN S

1шт.

31

S8000141

O-RING P14

desc: JOINT TORIQUE

3шт.

32

2181-1702D9

ELBOW;90ЎЖ PF1/2-PF3/8

desc: COUDE

2шт.

34

2184-1036D268

HOSE PF3/8-1900L

desc: TUYAU FLEXIBLE

1шт.

35

2181-1126D14

ADAPTER PF1/4-PF1/4

desc: RACCORD ADAPTATEUR

1шт.

36

2184-1026D149

HOSE PF3/8-610L

desc: TUYAU FLEXIBLE

1шт.

37

2184-1036D238

HOSE PF3/8-500L

desc: TUYAU FLEXIBLE

1шт.

40

2184-1036D229

HOSE PF3/8-1400L

desc: TUYAU FLEXIBLE

1шт.

41

2181-2419D4

ELBOW;S PF1/2-PF3/8

desc: COUDE

1шт.

43

2124-1353D4

CLIP

SERIAL: 1001-1010

8шт.

43

2124-1353D20

CLIP

SERIAL: 1011

8шт.

44

S0508553

BOLT M8X1.25X14

desc: BOULON A 6 PANS

3шт.

45

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

5шт.

46

S4012533

NUT M8X1.25

desc: ECROU

5шт.

47

2181-1126D23

ADAPTER PFO1/2-PF3/8

desc: RACCORD

1шт.

48

2124-1353D18

CLIP

desc: ATTACHE

2шт.

49

S0511653

BOLT M10X1.5X16

desc: BOULON A 6 PANS

2шт.

50

2181-1950D2

PLUG PF3/8

desc: BOUCHON

1шт.

51

2181-1917D15

ADAPTER

desc: RACCORD

2шт.

52

S8180321

RING;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

53

2184-1026D324

HOSE PF3/8-900L

desc: TUYAU FLEXIBLE

1шт.

54

2181-2419D2

ELBOW

desc: COUDE

1шт.
