Запчасти Doosan Daewoo PEDAL BRACKET ASSY BODY PARTS

-

4197-2470B

PEDAL BRACKET ASS'Y

SERIAL: 1001-1017

-2шт.

-

4197-2470C

PEDAL BRACKET ASS'Y

SERIAL: 1018-1020

-2шт.

1

4197-2469A

BRACKET;PEDAL

desc: SUPPORT

1шт.

2

4305-1019A

SHAFT;PEDAL

desc: ARBRE

1шт.

3

4412-1105

PLATE

desc: PLAQUE

1шт.

4

4412-1104A

PLATE

desc: PLAQUE

1шт.

5

4109-9077

BEARING

desc: PALIER

2шт.

6

4420-9583

SERVICE ACC VALVE

desc: VANNE DE RESVOIR

1шт.

7

4460-9050

ACCUMULATOR

desc: RESERVOIR

1шт.

8

2181-2737D3

ADAPTER;S PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

1шт.

9

S8180321

SEAL RING

desc: BAGUE D'ETANCHEITE

1шт.

10

4549-9136

SWITCH STOP LAMP

desc: INTERRUPTEUR

1шт.

11

4129-1484

SPRING

desc: RESSORT

1шт.

12

4413-1011

ROD

SERIAL: 1001-1017

1шт.

12

4413-1011A

ROD

SERIAL: 1018

1шт.

13

S4012633

NUT M10X1.5

SERIAL: 1001-1017

1шт.

13

S4012633

NUT M10X1.5

SERIAL: 1018

2шт.

14

4116-1567A

STOPPER;BOSS

desc: ARRET

1шт.

15

S2205261

BOLT;SOCKET M6X1.0X30

desc: BOULON A 6 PANS CREUX

1шт.

16

4420-9606

VALVE;BRAKE

desc: VANNE DE FREIN

1шт.

17

2123-1057D7

PIN D10X27

desc: BROUCHE

1шт.

18

S5735351

PIN SPLIT D2.5X20

desc: BROUCHE

1шт.

19

S5010613

WASHER;PLAIN M10

desc: RONDELLE

2шт.

20

4161-9036

STEER MOUNT

desc: ENSEMBLE SUPPORT DE MONTAGE

4шт.

21

4134-1136

PEDAL

desc: PEDALE DE CONSOLE

2шт.

22

4161-2479A

RUBBER

desc: CAOUTCHOUC

2шт.

23

S2212061

BOLT;SOCKET M10X1.5X25

desc: BOULON A 6 PANS CREUX

4шт.

24

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

6шт.

25

S0509253

BOLT M8X1.25X30

desc: BOULON A 6 PANS

5шт.

26

S4012533

NUT M8X1.25

desc: ECROU

5шт.

27

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

11шт.

28

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

7шт.

29

S0712053

BOLT M10X1.25X25

desc: BOULON A 6 PANS M10X1.25X25

2шт.

30

S0556353

BOLT M8X1.25X50

desc: BOULON A 6 PANS

3шт.

31

S0512353

BOLT M10X1.5X35

desc: BOULON A 6 PANS

4шт.

33

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

2шт.

34

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

3шт.

35

S5010313

WASHER;PLAIN M6

desc: RONDELLE

7шт.

36

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

37

S0504553

BOLT M6X1.0X14

desc: BOULON A 6 PANS

2шт.

38

4549-9135

SWITCH. PRESSURE

desc: INTERRUPTEUR

1шт.

39

4181-2776

ADAPTER;S PF1/4-PT1/8

desc: ADAPTEUR

1шт.

40

S8000111

O-RING P11

desc: JOINT TORIQUE

1шт.

41

S8000181

O-RING P18

desc: JOINT TORIQUE

1шт.

42

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

43

2114-1058D1

WASHER

desc: RONDELLE

4шт.
