Запчасти Doosan Daewoo COOLER PIPING BODY PARTS

-

4400-2051

COOLER PIPING

SERIAL: 1001-1020

-2шт.

1

4185-1761

HOSE

desc: TUYAU

1шт.

2

4185-1762

HOSE

desc: TUYAU

1шт.

3

2181-1112D4

ELBOW PT3/4-PF3/4-45ЎЖ

desc: COUDE

2шт.

4

2181-1702D1

ELBOW PF3/4-PFO3/4

desc: RACCORD

2шт.

5

S8000231

O-RING P23

desc: JOINT TORIQUE

4шт.

6

2184-1070D52

HOSE PF3/4-2450L

desc: TUYAU FLEXIBLE

1шт.

7

2184-1036D89

HOSE PF3/4-1800L

desc: TUYAU FLEXIBLE

1шт.

8

2185-1308D23

HOSE 1200L

desc: TUYAU FLEXIBLE

1шт.

9

S0558953

BOLT M10X1.5X70

desc: BOULON A 6 PANS

2шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

10шт.

11

S5010613

WASHER;PLAIN M10

desc: RONDELLE

2шт.

12

2186-9005

DRAIN;COCK

desc: ROBINET

1шт.

13

2181-2104D3

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

14

S8450044

CLAMP;HOSE D44Ў­D63

desc: COLLIER

4шт.

15

S8450066

CLAMP;HOSE

desc: COLLIER

4шт.

16

2124-1353D5

CLIP

desc: ATTACHE

1шт.

17

S4012633

NUT M10X1.5

desc: ECROU M10X1.5

4шт.

18

2124-1353D7

CLIP

desc: ATTACHE

3шт.

19

4197-2377A

BRACKET

desc: SUPPORT

1шт.

20

2184-1036D367

HOSE PF1-480L

desc: TUYAU FLEXIBLE

1шт.

21

2181-1917D51

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

22

S8180311

RING;SEAL

desc: BAGUE

1шт.

23

S8450016

CLAMP;HOSE D16Ў­D26

desc: COLLIER

2шт.

24

4471-9059

FILTER;OIL T/M

desc: FILTRE

1шт.

25

4197-2378

BRACKET

desc: SUPPORT

1шт.

27

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

28

4423-1553

BLOCK

desc: BLOC

1шт.

29

S2262761

BOLT;SOCKET M10X1.25X55

desc: BOULON A 6 PANS CREUX

4шт.

30

S5110601

WASHER; SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

31

2180-1026D2

O-RING SAE3/4

desc: JOINT TORIQUE

1шт.

32

S8000291

O-RING P29

desc: JOINT TORIQUE

1шт.

33

2184-1026D234

HOSE PF3/4-640L

desc: TUYAU FLEXIBLE

1шт.

34

4181-2801

TEE PF3/4-PFO1-PT1/2

desc: TE

1шт.

35

2184-1026D423

HOSE PF3/4-570L

desc: TUYAU FLEXIBLE

1шт.

36

4181-2802

TEE PF3/4-PF3/8-PF3/4

desc: TE

1шт.

37

2181-1126D1

ADAPTER PF3/4-PF3/4

desc: RACCORD

1шт.
