Запчасти Doosan Daewoo REMOCON VALVE-THREE LEVER PILOT PIPING-THREE LEVER+3 SPOOL

-

4420-1240

REMOCON VALVE-THREE LEVER

desc: CONTROLEUR

1шт.

1

2133-2016

LEVER

desc: LEVIER

3шт.

2

2188-1010

CAP

desc: CHAPEAU

3шт.

3

S5740341

PIN;SPRING

desc: BROUCHE

3шт.

4

S3640153

TAPPING;SCREW

desc: VIS

3шт.

5

4549-1149

SWITCH ASS'Y

desc: INTERRUPTEUR

1шт.

6

S801140H

TERMIANL

desc: TERMIANL

1шт.

7

S800140H

TERMIANL

desc: TERMIANL

1шт.

8

4112-1251

BAR;HANDLE

desc: LEVIER

1шт.

9

4112-1252

BAR;HANDLE

desc: LEVIER

1шт.

10

4112-1253

BAR;HANDLE

desc: LEVIER

1шт.

11

4420-9560

REMOCON VALVE;THREE LEVER

desc: CONTROLEUR

1шт.

11-1

43-210

O-RING

desc: . JOINT TORIQUE

2шт.

11-2

43-213

O-RING

desc: . JOINT TORIQUE

2шт.

11-3

51768-1

BOOT

desc: . GAINE DE PROTECTION

3шт.

11-4

51770

RING;RETAINING

desc: . RONDELLE DE RETENUE

6шт.

11-5

51774

PIN;PIVOT

desc: . GOUJON

3шт.

11-6

52206-20

MAGNETIC SHELL

desc: . MAGNETQUE COQUE

3шт.

11-7

53402-A3

PLUNGER ASS'Y

desc: . PLONGEUR

6шт.

11-8

55686

GASKET

desc: . JOINT

3шт.

11-9

55687

GASKET

desc: . JOINT

3шт.

11-10

51614-A6

METERING CAPSULE ASS'Y

desc: . PLUNGEUR

6шт.

11-11

51615-105

PLUNGER CAPSULE ASS'Y

desc: . PLUNGEUR

3шт.

11-12

52735-58

PLUNGER FEEL CAPSULE ASS'Y

desc: . PLUNGEUR

3шт.

11-13

53749

SEAL KIT;METERING CAPSULES

desc: . KIT DE REPARATION

-2шт.

11-14

53817

SEAL KIT;PLUNGER CAPSULES

desc: . KIT DE REPARATION

-2шт.

12

S4012733

NUT M12X1.75

desc: ECROU

3шт.
