Запчасти Doosan Daewoo AIRCONDITIONER(2) BODY PARTS

-

4920-1095

COOLER & HEATER ASS'Y

SC: D

-2шт.

16

4185-1771A

HOSE;DISCHARGE 2000L

desc: TUYAU

1шт.

16A

2180-6088

O-RING(COMP) D11/T2.4

desc: . JOINT TORIQUE

1шт.

16B

2180-6089

O-RING(COND) D10.77/T1.78

desc: . JOINT TORIQUE

1шт.

16C

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

17

4185-1772A

HOSE;SUCTION 2000L

desc: TUYAU

1шт.

17A

2180-6086

O-RING(COMP) D14.8/T2.4

desc: . JOINT TORIQUE

1шт.

17B

2180-6087

O-RING(EVA) D13.9/T1.78

desc: . JOINT TORIQUE

1шт.

17C

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

18

520-00001

CONDENSER ASS'Y

desc: CONDENSEUR

1шт.

18A

520-00002

CONDENSER CORE ASS'Y

desc: . CONDENSEUR

1шт.

18B

2538-6018

FAN MOTOR ASS'Y 24V

desc: . MOTEUR

1шт.

18C

2520-6006

NET;CONDENSER

desc: . ENSEMBLE COMPRESSEUR

1шт.

19

S0560453

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

20

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M10

4шт.

21

S5010713

WASHER;PLAIN M12

SERIAL: 1001-1017

4шт.

21

S5010713

WASHER;PLAIN M12

SERIAL: 1018

8шт.

22

4185-1775D1

HOSE;LIQUID(1) 800L

desc: TUYAU FLEXIBLE

1шт.

22A

2180-6090

O-RING D6.07/T1.78

desc: . JOINT TORIQUE

2шт.

23

4185-1775D2

HOSE;LIQUID(2) 600L

desc: TUYAU

1шт.

23A

2180-6090

O-RING D6.07/T1.78

desc: . JOINT TORIQUE

2шт.

24

2204-6039A

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

25

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

26

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

2шт.

28

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

6шт.

29

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

6шт.

30

2114-1058D29

WASHER;PLAIN M8

desc: RONDELLE

6шт.

38

2124-1509D6

CLIP D42/M8

desc: ATTACHE

2шт.

41

S4012733

NUT M12X1.75

SERIAL: 1018

4шт.
