1
65.01101-6054H
CYLINDER BLOCK ASS'Y
SERIAL: 030617
1шт.
1
65.01101-6054I
CYLINDER BLOCK ASS'Y
SERIAL: 041214
1шт.
1
65.01101-6054J
CYLINDER BLOCK ASS'Y
SERIAL: 060726
1шт.
1
65.01101-6054L
CYLINDER BLOCK ASS'Y
SERIAL: 060727
1шт.
2
65.01101-0031D
BLOCK;CYLINDER
SERIAL: 030617
1шт.
2
65.01101-0031F
BLOCK;CYLINDER
SERIAL: 030618
1шт.
3
65.01105-1004
CAP;BEARING(F.M.R)
SERIAL: 060726
6шт.
3
65.01105-1044A
CAP;BEARING(F.M.R)
SERIAL: 060727
6шт.
5
65.01105-1003
CAP;BEARING(NO.4)
SERIAL: 060726
1шт.
5
65.01105-1043A
CAP;BEARING(NO.4)
SERIAL: 060727
1шт.
7
65.91710-0001
RING;BEARING CAP STOPPER
desc: . BAGUE
2шт.
8
65.90020-0066A
BOLT;HEX. BEARING CAP
desc: . BOULON A 6 PANS
14шт.
9
65.04410-0007A
BUSH;CAM SHAFT
SERIAL: 021109
1шт.
9
65.04410-0007B
BUSH;CAM SHAFT
SERIAL: 041214
1шт.
9
65.04410-0007C
BUSH;CAM SHAFT
SERIAL: 060726
1шт.
9
65.04410-0007D
BUSH;CAM SHAFT
SERIAL: 060727
1шт.
10
65.04410-0006A
BUSH;CAM SHAFT
SERIAL: 021109
5шт.
10
65.04410-0006B
BUSH;CAM SHAFT
SERIAL: 041214
5шт.
10
65.04410-0006C
BUSH;CAM SHAFT
SERIAL: 041215
5шт.
11
65.90302-0009
PLUG;CORE
desc: . BOUCHON B28D
2шт.
12
06.15091-0319
PLUG;CORE
SERIAL: 030510
2шт.
12
65.90302-0041
PLUG;CORE
SERIAL: 030511
2шт.
13
06.15091-0322
PLUG;CORE
SERIAL: 030510
3шт.
13
65.90302-0042
PLUG;CORE
SERIAL: 030511
3шт.
15
65.90310-0030
SCREW;PLUG M12X1.25
desc: VIS
1шт.
16
06.56190-0704
RING;SEAL
desc: ANNEAU DU JOINT
1шт.
17
65.90320-0019
SCREW;PLUG PT1/8
desc: VIS
1шт.
18
06.15091-0313
PLUG;CORE
desc: BOUCHON
2шт.
19
65.90320-0022
SCREW;PLUG PT1/8
desc: VIS
10шт.
20
65.90201-0058
BOLT;STUD M14X1.5X45
desc: GOUJON
1шт.
21
65.91605-0001E
COVER
desc: COUVERCLE
1шт.
22
06.01913-3113
BOLT;HEX. M8X20
desc: BOULON A 6 PANS
2шт.
23
65.01112-0021A
COVER;PUSH ROD CHAMBER
desc: COUVERCLE
3шт.
25
65.90020-0049
BOLT;HEX
desc: BOULON A 6 PANS
6шт.
26
65.96507-0007
PACKING JOING BOLT
desc: BAGUE D'ETANCHEITE
6шт.
27
65.01110-6090B
METAL;MAIN STD
desc: PALIER
7шт.
27
65.01110-6091B
METAL;MAIN
SC: US
7шт.
27
65.01110-6092B
METAL;MAIN
SC: US
7шт.
28
65.01150-6010A
WASHER;THRUST
SERIAL: 060808
2шт.
28
65.01150-6008
WASHER;THRUST
SERIAL: 060809
2шт.
28
65.01150-6034A
WASHER;THRUST
SC: OS
2шт.
28
65.01150-6035A
WASHER;THRUST
SC: OS
2шт.
29
65.91615-0011
COVER
desc: COUVERCLE
1шт.
30
06.01913-3113
BOLT;HEX. M8X20
desc: BOULON A 6 PANS
2шт.
31
65.01201-0067
LINER;CYLINDER(ALTV)
SC: D
6шт.
31
65.01201-0068
LINER;CYLINDER(1A)
desc: CHEMISE DE CYLINDRE
6шт.
31
65.01201-0069
LINER;CYLINDER(1B)
desc: CHEMISE DE CYLINDRE
6шт.
31
65.01201-0070
LINER;CYLINDER(2A)
desc: CHEMISE DE CYLINDRE
6шт.
31
65.01201-0071
LINER;CYLINDER(2B)
desc: CHEMISE DE CYLINDRE
6шт.
36
65.01901-0020
GASKET(CHAMBER COVER)
desc: JOINT
3шт.
37
06.56021-0106
O-RING
desc: JOINT TORIQUE
1шт.
38
65.90310-0135
SCREW;PLUG M14X1.5
desc: VIS
1шт.
39
06.56190-0706
RING;SEAL
desc: ANNEAU DU JOINT
1шт.
40
65.05903A0013
GASKET
desc: JOINT
1шт.
41
65.98130-0040A
ADAPTER
SERIAL: 060424
1шт.
42
65.06310-6003
PLUG;DRAIN
SERIAL: 021123
1шт.
42
65.06310-6003A
PLUG;DRAIN
SERIAL: 060424
1шт.
42
65.90310-0122
PLUG;DRAIN
SERIAL: 060425
1шт.
44
04.50010-0811
HOSE;VINYL
SERIAL: 060424
1шт.
45
06.56190-0713
RING;SEAL
desc: ANNEAU DU JOINT
1шт.
48
06.56021-0102
O-RING
desc: JOINT TORIQUE
1шт.
52
65.05401-5002F
RELIEF VALVE ASS'Y
desc: COUVERCLE ETANCHE
1шт.
53
65.27441-7006
SWITCH;OIL PRESS
desc: CLIP
1шт.
55
65.97401-0050
CLIP;HOSE
SERIAL: 060424
1шт.
