Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

302
303
404
405
306
406
301
501
413
412
305
413
401
402
403
108
109
110
503
107
104
102
101
103
208
207
202
204
201

Артикул

Название

Примечание

Количество

101

65.02101-6018A

CRANK SHAFT ASS'Y

desc: ENSEMBLE VILEBREQUIN

1шт.

102

65.02101-0045A

SHAFT;CRANK

desc: . VILEBREQUIN

1шт.

103

06.22022-3212

PIN;PARALLEL

desc: . GOUJON

1шт.

104

65.02115-0013

GEAR;CRANK SHAFT

SERIAL: 021010

1шт.

104

65.02115-0009

GEAR;CRANK SHAFT

SERIAL: 021011

1шт.

107

65.02120-0002

RING;OIL THROWER

desc: BAGUE

1шт.

108

65.90501-0006

NUT

desc: ECROU

1шт.

109

65.93020-0015

BUSH;TAPER

desc: COUSSINET

1шт.

110

65.91501-0006

KEY;SLIDING

desc: KEY

1шт.

201

65.02301-5055

FLY WHEEL ASS'Y

desc: ENSEMBLE VOLANT

1шт.

202

65.02310-0006

GEAR;STARTING RING

desc: . ENGRENAGE

1шт.

204

65.02301-0203

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

207

06.01494-4506

BOLT;HEX. M16X1.5X35

desc: BOULON A 6 PANS

6шт.

208

06.16731-2111

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

301

65.02401-6161

CONNECTING ROD ASS'Y

SERIAL: 030818

6шт.

301

65.02401-6161A

CONNECTING ROD ASS'Y

SERIAL: 040424

6шт.

301

65.02401-6028

CONNECTING ROD ASS'Y

SERIAL: 041208

6шт.

301

65.02401-6028A

CONNECTING ROD ASS'Y

SERIAL: 041209

6шт.

302

65.02401-0161

ROD;CONNECTING

SERIAL: 030818

1шт.

302

65.02401-0161A

ROD;CONNECTING

SERIAL: 040424

1шт.

302

65.02401-0016

ROD;CONNECTING

SERIAL: 040425

1шт.

303

65.02405-1060

BUSH

SC: B

1шт.

305

65.02411-0006

BOLT

SERIAL: 040424

2шт.

305

65.02411-0006A

BOLT

SERIAL: 040425

2шт.

306

65.02410-6003A

METAL;CON ROD STD

desc: PALIER

6шт.

401

65.02501-0195

PISTON(ALTV)

SC: D

6шт.

402

65.02501-0196

GRADE(A GRADE)

desc: GRANDEUR

6шт.

403

65.02501-0197

GRADE(B GRADE)

desc: GRANDEUR

6шт.

404

65.02503-0099

RING;TOP

desc: SEGMENT COUP DE FEU

6шт.

405

65.02503-0116

RING;SECOND

desc: SEGMENT DE COMPRESSION

6шт.

406

65.02503-0114

RING;OIL

desc: SEGMENT RACLEUR

6шт.

412

65.02502-0002

PIN;PISTON

desc: GOUPILLE

6шт.

413

06.29020-0121

RING;RETAINING

desc: RONDELLE DE RETENUE

12шт.

501

65.02601-5019

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

503

65.02122-0001

COVER;DUST

desc: COUVERCLE

1шт.

Выбрано товаров: 35
