Запчасти Doosan Daewoo WATER PUMP & COOLING FAN ENGINE PARTS

101

65.06500-6144A

WATER PUMP ASS'Y

desc: ENSEMBLE POMPE A EAU

1шт.

102

65.06501-0214

HOUSING

SC: D

1шт.

103

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

104

65.93410-0027

BEARING

desc: . PALIER

1шт.

105

06.29020-0132

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

106

65.06504-0033

HUB;V-BELT PULLEY

desc: . MOYEU

1шт.

107

65.06506-0021

IMPELLER

desc: . TURBINE

1шт.

108

65.06512-0002

COVER

desc: . COUVERCLE

1шт.

109

65.06901-0035A

GASKET

desc: . JOINT

1шт.

110

06.04200-9009

SCREW;CROSS M8X20

desc: . VIS

3шт.

111

06.01493-4215

BOLT;HEX. M10X1.25X80

desc: BOULON A 6 PANS

1шт.

112

06.01493-4211

BOLT;HEX. M10X1.25X60

SERIAL: 040728

2шт.

112

06.01493-4212

BOLT;HEX. M10X1.25X65

SERIAL: 040729

2шт.

113

06.01913-3218

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

1шт.

114

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

115

65.06606-0039

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

116

65.06901B0002

GASKET;WATER PUMP

desc: JOINT

1шт.

203

06.01913-3111

BOLT;HEX M8X16

desc: BOULON A 6 PANS

4шт.

209

65.96801-0124

BELT;POLY

SERIAL: 040205

1шт.

209

65.69801-0124A

BELT;POLY

SERIAL: 040206

1шт.
