Запчасти Doosan Daewoo CONTROL VALVE PIPING-3 SPOOL BODY PARTS

-

400-00379

CONTROL VALVE PIPING

SC: D

-2шт.

1

4197-2419A

BRACKET

desc: SUPPORT

2шт.

2

2124-1025D2

CLAMP;PIPE

desc: COLLIER

2шт.

3

4182-1790C

PIPE

desc: CONDUITE

1шт.

4

4182-1789B

PIPE

desc: CONDUITE

1шт.

5

2184-1036D440

HOSE PF3/4(ST-90)-780L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1036D109

HOSE PF3/4(ST-90)-565L

desc: TUYAU FLEXIBLE

1шт.

7

2184-1054D57

HOSE PF1/2(ST-ST)-1050L

desc: TUYAU FLEXIBLE

4шт.

8

S2215566

BOLT M12X1.75X45

desc: BOULON A 6 PANS

3шт.

9

2181-1702D78

ELBOW UN1 3/16-PF3/4

desc: COUDE

1шт.

10

2181-1702D79

ELBOW UN1 3/16-PF3/4

desc: COUDE

1шт.

11

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

4шт.

12

2181-1126D88

ADAPTER PFO1/2-PF3/4

desc: RACCORD ADAPTATEUR

4шт.

13

S0558653

BOLT M10X1.5X55

desc: BOULON A 6 PANS

3шт.

14

S4012633

NUT

desc: ECROU

3шт.

15

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

10шт.

16

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

9шт.

17

S0511853

BOLT M10X20

desc: BOULON A 6 PANS

4шт.

18

S8000181

O-RING

desc: JOINT TORIQUE

8шт.

19

S8040141

O-RING

desc: JOINT TORIQUE

6шт.

20

4197-2418A

BRACKET

desc: SUPPORT

1шт.

21

2124-1025D1

CLAMP

desc: ATTACHE DE TUYAU

2шт.

22

4182-1792A

PIPE

desc: CONDUITE

1шт.

23

4182-1791A

PIPE

desc: CONDUITE

1шт.

24

2184-1026D382

HOSE PF3/4(ST-ST)-870L

desc: TUYAU FLEXIBLE

2шт.

25

2181-1126D140

ADAPTER UN1 3/16-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

26

DS2213158

ADAPTER UN1 3/16-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

27

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

28

S5110701

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

29

420-00142

VALVE;CONTROL 3-SPOOL

desc: TIROIR DE COMMANDE

1шт.

30

2181-1950D16

PLUG

desc: BOUCHON

2шт.
