Запчасти Doosan Daewoo DRIVING SYSTEM ENGINE PARTS

1

65.02101-7065B

CRANK SHAFT

desc: VILEBREQUIN

1шт.

2

65.02130-0001

RING;WEAR(FRONT)

desc: SEGMENT D'USURE

1шт.

3

06.22022-3065

PIN;PARALLEL

desc: BROCHE

1шт.

4

65.02115-0066

GEAR;C.R.S

desc: PIGNON DE VILEBREQUIN

1шт.

5

65.01505-0007

RING;OIL THROWER

desc: BAGUE

1шт.

6

65.01110-6529

BEARING;MAIN

desc: ETANCHEITE

3шт.

7

65.01111-6539

BEARING;THRUST

desc: ETANCHEITE

1шт.

10

65.02201-7032

DAMPER;VISCOUS(ALT)

desc: AMORTISSEUR DE VIBRATIONS

1шт.

13

65.90020-0062B

BOLT;HEX M10X20

desc: BOULON A 6 PANS

6шт.

20

65.02301-5142

FLYWHEEL

desc: VOLANT

1шт.

21

65.02301-0286

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

22

65.02310-0073D

GEAR;RING

desc: . PIGNON

1шт.

23

65.02130-0002

RING;WEAR(REAR)

desc: BAGUE

1шт.

24

65.91303-0005

PIN;TAPER

desc: BROCHE

1шт.

25

65.90020-0127

BOLT;FLY WHEEL

desc: BOULON A 6 PANS

10шт.

30

65.02401-6027B

ROD;CONNECTING

desc: BIELLE

6шт.

31

65.02401-0015B

ROD;CONNECTING

SC: D

1шт.

32

65.02405-0008

BUSH;CONNECTING ROD

SC: B

1шт.

33

65.02411-0008

BOLT;CONNECTING ROD

desc: . VIS DE BIELLE

2шт.

34

65.02410-0110B

BEARING;CONNECTING ROD

desc: PALIER

6шт.

34

65.02410-0111B

BEARING;CON. ROD(0.10)

SC: US

6шт.

34

65.02410-0112B

BEARING;CON. ROD(0.25)

SC: US

6шт.

35

65.02410-0120B

BEARING;CONNECTING ROD

desc: PALIER

6шт.

35

65.02410-0121B

BEARING;CON. ROD(0.10)

SC: US

6шт.

35

65.02410-0122B

BEARING;CON. ROD(0.25)

SC: US

6шт.

40

65.02501-0705

PISTON

SERIAL: 061010

6шт.

40

65.02501-0705A

PISTON

SERIAL: 061011

6шт.

41

65.02503-0130

RING;PISTON

desc: BAGUE

6шт.

42

65.02503-0131

RING;PISTON

desc: BAGUE

6шт.

43

65.02503-0678

RING;PISTON OIL(GN)

desc: BAGUE

6шт.

44

65.02502-0081

PIN;PISTON

desc: AXE DE PISTON

6шт.

45

65.90815-0022A

RING;LOCK

desc: BAGUE

12шт.

50

65.02601-0220

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

51

06.02106-0824

BOLT

desc: BOULON A 6 PANS

8шт.
