Запчасти Doosan Daewoo FLYWHEEL HOUSING ENGINE PARTS

1

65.01401-5035

HOUSING;FLYWHEEL

desc: BOITIER

1шт.

2

65.01402-0010

COVER;FLYWHEEL HOUSING

desc: COUVERCLE

1шт.

3

65.01904-0029

GASKET

desc: JOINT

1шт.

4

06.01923-3118

BOLT ASS'Y M8X35

desc: BOULON 6 PANS

4шт.

5

65.01510-0141

OIL SEAL;RR

desc: JOINT

1шт.

6

65.90720-0109

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

7

65.90020-0065

BOLT;HEX

SERIAL: 060504

2шт.

7

REP_PNO: 65.96501-0104

-1шт.

7

65.90020-0137

BOLT;HEX

SERIAL: 060505

2шт.

7-1

65.96501-0104

O-RING

SERIAL: 060505

2шт.

8

65.01904-0030

GASKET

SERIAL: 060629

1шт.

8

65.01904-0038

GASKET

SERIAL: 060630

1шт.

9

65.01904-0031

GASKET

SERIAL: 060425

1шт.

9

65.01904-0031A

GASKET

SERIAL: 060629

1шт.

9

65.01904-0037

GASKET

SERIAL: 060630

1шт.

10

65.90020-0223

BOLT;F.W.H

desc: BOULON A 6 PANS

8шт.

11

65.90020-0183B

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

12

65.90020-0133

BOLT;HEX

desc: BOULON A 6 PANS

1шт.

13

65.90020-0130

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

14

06.01954-3331

BOLT;SPACER M12X1.5X100

desc: BOULON A 6 PANS

2шт.

15

65.91701-0468

SPACER

desc: DOUILLE D'ECARTEMENT

2шт.

16

06.16731-6109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

2шт.

17

65.01414-0004A

COVER;TIMING POINT HOLE

desc: COUVERCLE

1шт.

18

06.01923-3110

BOLT ASS'Y M8X12

desc: BOULON A 6 PANS

2шт.
