Запчасти Doosan Daewoo MAIN PIPING - ONE WAY OPTIONAL PARTS

-

K1002482B

MAIN PIPING-ONE WAY

SC: D

-2шт.

1

426-00267A

VALVE;RELIEF

desc: VANNE

1шт.

2

423-00193B

BLOCK

desc: BLOC

1шт.

3

181-00121D8

TEE

desc: TE

1шт.

4

DS2232111

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

5

DS2232107

ADAPTER

desc: ADAPTEUR

1шт.

6

2181-4133D35

ADAPTER

desc: RACCORD ADAPTEUR

1шт.

7

DS2065026

HOSE

desc: TUYAU FLEXIBLE

1шт.

8

DS2012175

HOSE

desc: TUYAU FLEXIBLE

1шт.

9

DS2016062

HOSE

desc: TUYAU FLEXIBLE

1шт.

10

DS2016062

HOSE

desc: TUYAU FLEXIBLE

1шт.

11

2181-9081

FLANGE;SPLIT

desc: BRIDE

2шт.

12

S2215566

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

4шт.

13

S0561266

BOLT

desc: BOULON A 6 PANS

2шт.

14

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE M12

4шт.

15

DS0025020

BOLT;SET

desc: BOULON A 6 PANS

8шт.

16

S0561066

BOLT

desc: BOULON A 6 PANS

2шт.

17

2180-1026D19

O-RING

desc: JOINT TORIQUE

1шт.

18

S8000291

O-RING

desc: JOINT TORIQUE

3шт.

19

S8030161

O-RING

desc: JOINT TORIQUE

3шт.

20

2180-1026D37

O-RING

desc: JOINT TORIQUE

1шт.

21

K1007520

BRACKET

desc: SUPPORT

1шт.

22

K1007521

BRACKET

desc: SUPPORT

1шт.

24

S8000381

O-RING

desc: JOINT TORIQUE

1шт.

41

K1006175

PLATE

desc: PLAQUE

1шт.

42

S8000291

O-RING

desc: JOINT TORIQUE

1шт.

43

DS2412017

TEE

desc: TE

1шт.

44

2180-1026D37

O-RING

desc: JOINT TORIQUE

2шт.

45

DS2023220

HOSE

desc: TUYAU FLEXIBLE

1шт.
