Запчасти Doosan Daewoo FUEL SYSTEM ENGINE PARTS

1

65.96340-5052

HOSE;RUBBER;RING JOINT

desc: TUYAU CAOUTCHOUC

1шт.

2

65.96340-5053

HOSE;RUBBER;RING JOINT

desc: TUYAU CAOUTCHOUC

1шт.

3

65.98130-0229

ADAPTER

desc: RACCORD ADAPTATEUR

4шт.

4

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

4шт.

5

65.12301-5239

PIPE;FUEL

desc: CANALISATION DE GAZOLE

2шт.

6

65.98130-0154

ADAPTER

desc: ADAPTEUR

6шт.

7

06.56180-0712

RING;SEAL A8X14

desc: BAGUE D'ETANCHEITE

8шт.

8

65.96507-0055

RING;SEAL

desc: BAGUE

6шт.

9

65.98150-0042A

SCREW;HOLLOW M8X1

desc: VIS CREUSE

4шт.

10

65.98130-0155

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

11

65.96330-7001

HOSE;RUBBER;RING JOINT

desc: TUYAU CAOUTCHOUC

1шт.

12

65.96330-0015

HOSE;RUBBER;RING JOINT

desc: . TUYAU CAOUTCHOUC

1шт.

13

65.96330-0016

HOSE;RUBBER;RING JOINT

desc: . TUYAU CAOUTCHOUC

1шт.

14

65.96330-0017

HOSE;RUBBER;RING JOINT

desc: . TUYAU CAOUTCHOUC

1шт.

15

65.52101-0004

REGULATOR;PRESSURE

desc: . REGULATEUR

1шт.

16

65.97440-0045

CLAMP;HOSE

desc: . COLLIER

4шт.

17

65.98150-0015B

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

18

06.56180-0712

RING;SEAL A8X14

desc: BAGUE D'ETANCHEITE

2шт.

20

65.12301-5271

PIPE;FUEL

desc: CANALISATION DE GAZOLE

1шт.

21

06.78144-2404

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

22

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

23

65.12303-0002

BRACKET;FUEL PIPE

desc: SUPPORT

1шт.

24

65.96330-0014

HOSE;RUBBER;RING JOINT

desc: TUYAU CAOUTCHOUC

1шт.

25

65.97440-0045

CLAMP;HOSE

desc: COLLIER

2шт.

30

06.78190-0206

CONNECTION;SCREW

desc: VIS

2шт.

31

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

32

65.97440-0005

CLAMP;HOSE

desc: COLLIER

1шт.

33

65.12301-5252

PIPE;FUEL

desc: CANALISATION DE GAZOLE

1шт.

34

65.12301-5241

PIPE;FUEL

desc: CANALISATION DE GAZOLE

1шт.

35

65.98150-0029

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

36

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

37

65.97401-5025

CLIP;PIPE

desc: CLIP DE FIXATION

1шт.

38

06.01283-6915

BOLT;HEX M6X25

desc: BOULON A 6 PANS

1шт.

40

65.12303-0006

BRACKET;FUEL PIPE

desc: SUPPORT

1шт.

41

06.11063-9216

NUT;HEX

SERIAL: 051103

2шт.

42

06.16731-2109

WASHER;SPRING A12

SERIAL: 051103

2шт.

43

06.78190-0206

CONNECTION;SCREW

desc: VIS

2шт.

44

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

45

65.12301-5268

PIPE;FUEL

desc: CONDUITE

2шт.

50

65.12501-7085B

FUEL FILTER ASS'Y

SERIAL: 060513

1шт.

50

65.12501-7093

FUEL FILTER ASS'Y

SERIAL: 060514

1шт.

51

65.12504-5019

COVER;FUEL FILTER

SERIAL: 060513

1шт.

51

65.12504-6001

COVER;FUEL FILTER

SERIAL: 060514

1шт.

52

65.12503-5020B

ELEMENT;FUEL FILTER

SERIAL: 060513

1шт.

52

65.12503-5027

ELEMENT;FUEL FILTER

SERIAL: 060514

1шт.

53

06.01923-3218

BOLT ASS'Y M10X35

desc: BOULON A 6 PANS

2шт.

54

65.12540-0054

BRACKET;FUEL FILTER

desc: SUPPORT

1шт.

55

06.01913-3218

BOLT ASS'Y M10X35

desc: BOULON A 6 PANS

3шт.

56

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE

1шт.

57

65.90201-0131

BOLT;STUD

desc: GOUJON

1шт.
