Запчасти Doosan Daewoo MAIN PIPING - TWO WAY OPTIONAL PARTS

-

K1003191E

MAIN PIPING-TWO WAY

SC: D

-2шт.

1

426-00248A

VALVE;SELECT

desc: VANNE

1шт.

2

426-00249A

VALVE;SELECT

desc: VANNE

1шт.

3

2181-4133D6

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

4

DS2232111

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

5

DS2232107

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

6

2181-4133D35

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

7

181-00121D8

TEE

desc: TE

1шт.

8

K1012112

PIPE

desc: CONDUITE

1шт.

9

K1012114A

BRACKET

desc: SUPPORT

1шт.

10

DS2026142

HOSE

desc: TUYAU FLEXIBLE

1шт.

11

DS2016058

HOSE

desc: TUYAU FLEXIBLE

1шт.

12

DS2012179

HOSE

SERIAL: 5001-5010

1шт.

12

DS2012243

HOSE

SERIAL: 5011

1шт.

13

DS2016059

HOSE

desc: TUYAU FLEXIBLE

1шт.

14

DS2016059

HOSE

desc: TUYAU FLEXIBLE

1шт.

15

DS0025020

BOLT;SET

desc: BOULON A 6 PANS

10шт.

16

S0561466

BOLT

desc: BOULON A 6 PANS

2шт.

17

2180-1026D19

O-RING

desc: JOINT TORIQUE

4шт.

18

S8000291

O-RING

desc: JOINT TORIQUE

4шт.

19

S8030161

O-RING

desc: JOINT TORIQUE

4шт.

20

S0561266

BOLT

desc: BOULON A 6 PANS

2шт.

21

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

5шт.

22

S5010713

WASHER;PLAIN

desc: RONDELLE

1шт.

24

S0561066

BOLT

desc: BOULON A 6 PANS

1шт.

25

2180-1026D37

O-RING

desc: JOINT TORIQUE

2шт.

26

2124-1025D5

CLAMP

desc: COLLIER

1шт.

27

K1012113

PIPE

desc: CONDUITE

1шт.

28

S2215566

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

16шт.

29

2181-9081

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

4шт.

31

S8000381

O-RING

desc: JOINT TORIQUE

1шт.

32

K1007520

BRACKET

desc: SUPPORT

1шт.

33

K1007521

BRACKET

desc: SUPPORT

1шт.

41

K1004929A

PLATE

desc: PLAQUE

1шт.

42

S8000291

O-RING

desc: JOINT TORIQUE

1шт.

43

DS2412017

TEE

desc: TE

1шт.

44

2180-1026D37

O-RING

desc: JOINT TORIQUE

2шт.

45

DS2023222

HOSE

desc: TUYAU FLEXIBLE

1шт.
