Запчасти Doosan Daewoo WATER PUMP ENGINE PARTS

1

65.06301-0251

PIPE;COOLING WATER

desc: CONDUITE D'EAU DE REFROIDISSEMENT

1шт.

2

06.01923-3124

BOLT ASS'Y M8X65

desc: BOULON A 6 PANS

3шт.

3

51.06402-0062

THERMOSTAT

desc: THERMOSTAT

2шт.

4

06.56342-1208

O-RING 60X4

desc: JOINT TORIQUE

2шт.

5

65.06901A0069

GASKET

desc: JOINT

2шт.

10

65.06500-6173A

WATER PUMP ASS'Y

desc: ENSEMBLE POMPE A EAU

1шт.

11

65.06501-0021A

HOUSING;WATER PUMP

SC: D

1шт.

12

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

13

65.06506-0011D

IMPELLER

desc: . TURBINE

1шт.

14

65.93410-0024

BEARING;UNIT

desc: . PALIER

1шт.

15

06.29020-0132

RING;SNAP 55X2

desc: . BAGUE

1шт.

16

65.06503-0171

PULLEY;BELT

desc: . POULIE

1шт.

17

65.06504-0014

HUB;BELT PULLEY

desc: . MOYEU

1шт.

18

06.01913-3114

BOLT ASS'Y M8X22

desc: . BOULON A 6 PANS

6шт.

19

65.06901A0075

GASKET;WATER PUMP

desc: JOINT DE POMPE A EAU

1шт.

20

06.01913-3122

BOLT ASS'Y M8X55

desc: BOULON A 6 PANS

9шт.

21

65.06903A0008

GASKET;COOLING WATER PIPE

desc: JOINT(CONDUITE D'EAU)

1шт.

22

65.06301-5343

PIPE;COOLING WATER

desc: CONDUITE D'EAU DE REFROIDISSEMENT

1шт.

23

06.01923-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

2шт.
