Запчасти Doosan Daewoo OIL PUMP ENGINE PARTS

1
5
2
4
6
8
3
7
17
9
11
12
13
14
15
16
10
20
24
21
25
23
22
29
28
26
29
28
27

Артикул

Название

Примечание

Количество

1

65.05100-6188D

OIL PUMP ASS'Y

SERIAL: 060720

1шт.

1

65.05100-6188F

OIL PUMP ASS'Y

SERIAL: 060721

1шт.

2

65.05102-0053C

HOUSING;OIL PUMP

SERIAL: 060720

1шт.

2

65.05102-0053D

HOUSING;OIL PUMP

SERIAL: 060721

1шт.

3

65.05104-0005

GEAR;OIL PUMP

SERIAL: 060720

1шт.

3

65.05104-5012

GEAR;OIL PUMP

SERIAL: 060721

1шт.

4

65.05104-0006

GEAR;OIL PUMP

SERIAL: 060720

1шт.

4

65.05104-5013

GEAR;OIL PUMP

SERIAL: 060721

1шт.

5

65.05201-0063

GEAR OIL PUMP DRIVE

desc: . ENSEMBLE POMPE A HUILE

1шт.

6

65.05103-0110

COVER;OIL PUMP

SERIAL: 060720

1шт.

6

65.05103-0110C

COVER;OIL PUMP

SERIAL: 060721

1шт.

7

06.01013-9115

BOLT;HEX. M8X50

desc: . BOULON A 6 PANS

4шт.

8

06.22022-0909

PIN

desc: . GOUJON

4шт.

9

06.01913-3122

BOLT ASS'Y M8X55

desc: BOULON A 6 PANS

1шт.

10

65.05401-5014

RELIEF VALVE ASS'Y

desc: COUVERCLE ETANCHE

1шт.

11

65.05406-0008

HOUSING;REL.VALVE

desc: . CARTER

1шт.

12

65.05410-0006

PLUNGER;REL.VALVE

desc: . PLUGEUR

1шт.

13

65.97601-0102

SPRING;REL.VALVE

desc: . RESSORT

1шт.

14

65.90310-0119

SCREW;REL.VALVE

desc: . VIS

1шт.

15

06.01913-3125

BOLT ASS'Y M8X70

SERIAL: 060118

1шт.

15

06.01913-7127

BOLT ASS'Y M8X80

SERIAL: 060119

1шт.

16

06.01913-3126

BOLT ASS'Y M8X75

desc: BOULON

1шт.

17

65.05903A0015

GASKET;RELIEF VALVE

desc: JOINT

1шт.

20

65.05401-6002

RELIEF VALVE ASS'Y

desc: COUVERCLE ETANCHE

1шт.

21

65.05406-0019

HOUSING;RELIEF VALVE

desc: . CARTER

1шт.

22

65.05401-5030

RELIEF VALVE ASS'Y

desc: . ENSEMBLE DE CLAPET DE DECHARGE

1шт.

23

65.98150-0082

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

24

65.96501-0072

O-RING

desc: JOINT TORIQUE

1шт.

25

06.56190-0734

RING;SEAL

desc: BAGUE D'ETANCHEITE 2411-1010

1шт.

26

06.01923-3222

BOLT ASS'Y

desc: BOULON A 6 PANS

1шт.

27

65.05701-5553

PIPE;OIL

desc: TUYAU D'HUILE

1шт.

28

06.78190-0206

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

29

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

Выбрано товаров: 33
