Запчасти Doosan Daewoo OIL PAN ENGINE PARTS

1

65.05801-5240

PAN;OIL

desc: CARTER MOTEUR

1шт.

2

65.05904-0034

GASKET;OIL PAN

desc: JOINT

1шт.

3

65.90001-0148A

BOLT;HEX M8X35

desc: BOULON A 6 PANS

20шт.

4

65.05806-5117

GUIDE TUBE;OIL LEVEL GAUGE

desc: GARDE

1шт.

5

06.01913-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

1шт.

6

65.97401-0184

CLIP;PIPE

desc: CLIP DE FIXATION

1шт.

7

06.01923-3110

BOLT ASS'Y M8X12

desc: BOULON A 6 PANS

1шт.

8

65.05805-5231

GAUGE;OIL LEVEL

desc: JAUGE D'HUILE

1шт.

10

65.05701-6109

PIPE;OIL

desc: TUYAU D'HUILE

1шт.

12

65.05740-0039

BRACKET;OIL PIPE

desc: . SUPPORT

1шт.

13

65.97401-0080

CLIP;PIPE

desc: . ATTACHE

1шт.

14

06.01283-7117

BOLT;HEX. M8X30

desc: . BOULON A 6 PANS

1шт.

15

06.15010-2311

WASHER

desc: . RONDELLE

1шт.

16

65.90510-0012

NUT;CLEVELOC

desc: . ECROU

1шт.

17

06.01923-3118

BOLT ASS'Y M8X35

desc: BOULON A 6 PANS

2шт.

18

06.01913-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

1шт.

19

65.96601-0055

GASKET

desc: JOINT

1шт.

20

06.56190-0732

RING;SEAL A30X36

desc: CONTACT DE NIVEAU D'HUILE

1шт.

21

65.98125-5022

JOINT;DRAIN

SERIAL: 060720

1шт.

21

65.98125-5022A

JOINT;DRAIN

SERIAL: 060721

1шт.
