Запчасти Doosan Daewoo OIL COOLER ENGINE PARTS

1

65.05601-7077

OIL COOLER ASS'Y

desc: ENSEMBLE REFROIDISSEUR D'HUILE

1шт.

2

65.05604-5031

HOUSING;OIL COOLER

desc: . CARTER

1шт.

3

65.05601-0048

COOLER;OIL

desc: . RADIATEUR D'HUILE

1шт.

4

65.96601-0221B

GASKET

desc: . JOINT

2шт.

5

06.01923-3124

BOLT ASS'Y M8X65

desc: . BOULON A 6 PANS

3шт.

6

06.01913-7127

BOLT ASS'Y M8X80

desc: . BOULON A 6 PANS

1шт.

7

06.15010-2311

WASHER

desc: . RONDELLE

1шт.

8

65.90310-0134

SCREW;PLUG

desc: . BOUCHON FILETE

2шт.

9

06.56190-0732

RING;SEAL A30X36

desc: . BAGUE D'ETANCHEITE

2шт.

10

65.90310-0133

SCREW;PLUG

desc: . BOUCHON FILETE

1шт.

11

06.56190-0726

RING;SEAL 26X31

desc: . BAGUE

1шт.

12

06.02097-8306

BOLT;SOCKET

desc: . BOULON

1шт.

13

06.16731-2105

WASHER;SPRING A6

desc: . RONDELLE ELASTIQUE

1шт.

14

65.90310-0131

SCREW;PLUG

desc: . BOUCHON FILETE

1шт.

15

06.56190-0713

RING;SEAL A18X24

desc: . BAGUE D'ETANCHEITE

1шт.

20

65.05901B0016

GASKET;OIL COOLER

desc: JOINT

1шт.

21

06.01924-3225

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

2шт.

22

06.01923-3218

BOLT ASS'Y M10X35

desc: BOULON A 6 PANS

5шт.

23

65.90001-0130

BOLT;HEX. M10X35

desc: BOULON A 6 PANS

1шт.

24

06.01923-3228

BOLT ASS'Y M10X85

desc: BOULON A 6 PANS

2шт.

25

06.01923-3219

BOLT ASS'Y M10X40

desc: BOULON A 6 PANS

1шт.

26

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

1шт.

27

06.15010-4312

WASHER;PLAIN 10.5

desc: RONDELLE PLATE

1шт.
