Запчасти Doosan Daewoo EXHAUST MANIFOLD ENGINE PARTS

1

65.08101-0236

MANIFOLD;EXHAUST

SERIAL: 050915

2шт.

1

65.08101-0236A

MANIFOLD;EXHAUST

SERIAL: 050916

2шт.

2

65.08901-0033A

GASKET;EXHAUST MANIFOLD

SERIAL: 050915

6шт.

2

65.08901-0043

GASKET;EXHAUST MANIFOLD

SERIAL: 050916

6шт.

3

65.90535-0001

NUT;HEX

desc: ECROU

12шт.

4

65.08112-6011

JOINT;EXHAUST MANIFOLD

desc: JOINT

1шт.

5

65.08112-6012

JOINT;EXHAUST MANIFOLD

desc: JOINT

1шт.

6

65.90201-0113

BOLT;STUD

desc: GOUJON

8шт.

7

65.90535-0001

NUT;HEX

desc: ECROU

8шт.

10

65.08110-0007

PIPE;COLLECTOR;EXHAUST

desc: CONDUITE

1шт.

11

06.01283-7524

BOLT;HEX. M16X2X65

desc: BOULON A 6 PANS

2шт.

12

06.16731-2111

WASHER;SPRING.A16

desc: RONDELLE ELASTIQUE

2шт.

13

06.01013-9219

BOLT;HEX. M10X1.5X70

desc: BOULON A 6 PANS

2шт.

14

65.08120-5103

SCREEN;HEAT

desc: ECRAN THERMIQUE

2шт.

15

06.01923-2910

BOLT ASS'Y M6X12

desc: BOULON A 6 PANS

8шт.

16

65.08120-0030

SCREEN;HEAT

desc: ECRAN THERMIQUE

1шт.

17

06.01923-2910

BOLT ASS'Y M6X12

desc: BOULON A 6 PANS

2шт.
