Запчасти Doosan Daewoo TRAVEL REDUCTION GEAR HYDRAULIC PARTS

-

K1010210A

MOTOR;TRAVEL

desc: MOTEUR

2шт.

1

K9003720

REDUCTION GEAR

desc: VITESSE DE REDUCTION

1шт.

1-1

-

HOLDER;FLANGE

SC: D

1шт.

1-2

K9003721

SEAL;FLOATING

desc: JOINT

2шт.

1-3

K9003722

BEARING;ANGULAR

desc: ROULEMENT

1шт.

1-4

K9003723

NUT;RING

desc: ECROU

1шт.

1-5

K9003724

PLUG

desc: BOUCHON

2шт.

1-6

-

HOUSING

SC: D

1шт.

1-7

S6250110

BALL;STEEL

desc: BOULE

132шт.

1-8

2181-1116D1

PLUG

desc: BOUCHON

3шт.

1-9

K9003725

GEAR;PLANETARY

desc: PIGNON

4шт.

1-10

K9003726

BEARING;NEEDLE

desc: ROULEMENT

4шт.

1-11

K9003727

COLLAR

desc: COLLIER

4шт.

1-12

K9003728

WASHER;THRUST

desc: RONDELLE DE BUTEE

4шт.

1-13

K9003729

PLATE;THRUST

desc: PLAQUE

1шт.

1-14

K9003730

SCREW

desc: VIS

4шт.

1-15

K9003731

GEAR;SUN

desc: PIGNON

1шт.

1-16

S6500350

RING;SNAP

desc: BAGUE D'ARRET

1шт.

1-17

K9003732

HOLDER

desc: SUPPORT

1шт.

1-18

K9003733

GEAR;PLANETARY

desc: PIGNON

3шт.

1-19

K9003734

BEARING;NEEDLE

desc: ROULEMENT

3шт.

1-20

K9003735

RACE;INNER

desc: RACE INTERIEUR

3шт.

1-21

S5740770

PIN;SPRING

desc: GOUPILLE

3шт.

1-22

K9003736

GEAR;DRIVE

desc: PIGNON

1шт.

1-23

K9003737

THRUST PLATE KIT

desc: KIT DE PLAT DE POUSSEE

1шт.

1-24

K9003738

COVER

desc: COUVERCLE

1шт.

1-25

2180-1217D149

O-RING

desc: JOINT TORIQUE

1шт.

1-26

K9003739

WIRE

desc: FIL

1шт.

1-27

2.181-00284

PLUG

desc: BOUCHON

3шт.

1-28

2.181-00280

PLUG

desc: BOUCHON

2шт.
