Запчасти Doosan Daewoo SWING MOTOR HYDRAULIC PARTS

-

K1011374A

MOTOR;SWING

desc: MOTEUR

1шт.

1

-

REDUCTION GEAR

SC: D

1шт.

1-1

-

HOUSING

SC: D

1шт.

1-2

-

SHAFT;PINION

SC: D

1шт.

1-3

-

PLATE

SC: D

1шт.

1-4

-

COLLAR

SC: D

1шт.

1-5

-

BEARING;TAPER ROLLER

SC: D

1шт.

1-6

K9003766

SEAL;OIL

desc: JOINT

1шт.

1-7

-

BEARING;TAPER ROLLER

SC: D

1шт.

1-8

-

PLATE

SC: D

2шт.

1-9

-

COLLAR

SC: D

1шт.

1-10

K9003767

HOLDER

desc: SUPPORT

1шт.

1-11

K9003768

WASHER;THRUST

desc: RONDELLE DE BUTEE

4шт.

1-12

K9003769

RACE;INNER

desc: RACE INTERIEUR

4шт.

1-13

K9003770

BEARING;NEEDLE

desc: ROULEMENT

4шт.

1-14

K9003771

GEAR;PLANETARY

desc: PIGNON

4шт.

1-15

K9003772

PLATE;THRUST

desc: PLAQUE

1шт.

1-16

K9003773

SCREW

desc: VIS

4шт.

1-17

K9003774

GEAR;SUN

desc: PIGNON

1шт.

1-18

K9003775

HOLDER

desc: SUPPORT

1шт.

1-19

K9003776

WASHER;THRUST

desc: RONDELLE DE BUTEE

4шт.

1-20

K9003777

RACE;INNER

desc: RACE INTERIEUR

4шт.

1-21

K9003778

BEARING;NEEDLE

desc: ROULEMENT

4шт.

1-22

K9003779

GEAR;PLANETARY

desc: PIGNON

4шт.

1-23

K9003780

THRUST PLATE KIT

desc: KIT DE PLAT DE POUSSEE

1шт.

1-24

K9003781

GEAR;DRIVE

desc: PIGNON

1шт.

1-35

-

PLUG

SC: D

1шт.

1-36

S8000081

O-RING

desc: JOINT TORIQUE

1шт.

1-37

2180-1216D150

O-RING

desc: JOINT TORIQUE

1шт.

2

-

MOTOR;PISTON

SC: D

1шт.

2-1

K9003782

CASE

desc: CARTER

1шт.

2-2

K9003783

BEARING;BALL

desc: ROULEMENT

1шт.

2-3

K9003784

SHAFT

desc: ARBRE

1шт.

2-4

K9003785

PLATE;THRUST

desc: PLAQUE

1шт.

2-5

-

BLOCK;CYLINDER

SC: D

1шт.

2-6

K9003786

COLLAR

desc: COLLIER

1шт.

2-7

K9003787

SPRING

desc: RESSORT

1шт.

2-8

K9003788

WASHER

desc: RONDELLE

1шт.

2-9

S6510370

RING;SNAP

desc: BAGUE D'ARRET

1шт.

2-10

K9003789

PIN

desc: GOUPILLE

3шт.

2-11

K9003790

HOLDER;RETAINER

desc: SUPPORT

1шт.

2-12

K9003791

PLATE;RETAINER

desc: PLAQUE

1шт.

2-13

-

PISTON ASS'Y

SC: D

9шт.

2-14

K9003792

DISC

desc: DISQUE

1шт.

2-15

K9003793

PISTON;BRAKE

desc: PISTON

1шт.

2-16

S8011101

O-RING

desc: JOINT TORIQUE

1шт.

2-17

S8011351

O-RING

desc: JOINT TORIQUE

1шт.

2-18

K9003794

SEAT;SPRING

desc: SIEGE

2шт.

2-19

K9003795

SPRING ASS'Y;DISK

desc: RESSORT DE DISQUE

1шт.

2-20

-

O-RING

SC: D

1шт.

2-21

K9003797

COVER

desc: COUVERCLE

1шт.

2-22

K9003748

BEARING;BALL

desc: ROULEMENT

1шт.

2-23

K9003747

PIN

desc: GOUPILLE

1шт.

2-24

K9003746

PLATE;VALVE

desc: PLAQUE

1шт.

2-25

K9003798

PIN

desc: GOUPILLE

2шт.

2-26

S8000211

O-RING

desc: JOINT TORIQUE

2шт.

2-27

S2215271

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

5шт.

2-28

K9003799

ORIFICE

desc: ORIFICE

1шт.

2-38

K9003800

VALVE;RELIEF

desc: VANNE

2шт.

2-38A

S8000241

O-RING

desc: JOINT TORIQUE

1шт.

2-38B

S8000121

O-RING

desc: JOINT TORIQUE

1шт.

2-38C

S8060121

BACK UP RING

desc: BAGUE D'ETANCHEITE

1шт.

2-39

K9003801

VALVE;CHECK

desc: CAPTEUR

2шт.

2-40

K9003802

SPRING

desc: RESSORT

2шт.

2-41

2.181-00286

PLUG

desc: BOUCHON

2шт.

2-42

S8000141

O-RING

desc: JOINT TORIQUE

2шт.

2-43

K9003757

PLUG

desc: BOUCHON

2шт.

2-44

S8000081

O-RING

desc: JOINT TORIQUE

2шт.

2-45

K9003803

PLUG

desc: BOUCHON

1шт.

2-46

S8000111

O-RING

desc: JOINT TORIQUE

1шт.

3

S2215271

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

2шт.

A

K9003804

SEAL KIT;SWING MOTOR

desc: JOINT

1шт.

B1

K9003805

CYLINDER BLOCK KIT

desc: KIT DE BLOC CYLINDRE

1шт.

B6

K9003806

HOUSING ASS'Y

desc: LOGEMENT

1шт.
