Запчасти Doosan Daewoo MAIN PUMP - GEAR PUMP HYDRAULIC PARTS

-

K9003843

PUMP;GEAR

desc: POMPE DE PIGNON

1шт.

3

-

HOUSING

SC: D

1шт.

4

2.430-00169

COVER

desc: COUVERCLE

1шт.

5

K9003827

GEAR

desc: PIGNON

1шт.

6

K9003828

GEAR

desc: PIGNON

1шт.

7

2.412-00252

THRUST PLATE

desc: PLAQUE DE POUSSE

2шт.

10

2.412-00356

PLATE

desc: PLAQUE

1шт.

11

2.429-00017

GUIDE

desc: GUIDE

2шт.

12

2.414-00024

COUPLING

desc: ACCOUPLEMENT

1шт.

14

2.180-00388

O-RING

desc: JOINT TORIQUE

2шт.

15

S8010900

O-RING

desc: JOINT TORIQUE

1шт.

16

2.180-01054

RING;SQUARE

desc: BAGUE

1шт.

17

2.180-01055

RING;SQUARE

desc: BAGUE

2шт.

18

S8000061

O-RING

desc: JOINT TORIQUE

1шт.

19

S2212061

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

2шт.

21

S2211861

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

4шт.
