Запчасти Doosan Daewoo LUB.OIL SYSTEM ENGINE PARTS

1

K9004706

DIPSTICK;LUB.OIL

desc: JAUGEUR

1шт.

2

2.429-00043

GUIDE;DIPSTICK

desc: GUIDE

1шт.

3

K9004749

GASKET

desc: JOINT

1шт.

4

K9004728

PIPE ASS'Y;OIL INLET

desc: ENSEMBLE DE TUYAU

1шт.

5

2.120-00145

BOLT M8X35

desc: BOULON

2шт.

6

2.549-00005

SWITCH;OIL PRESS

desc: COMMUTATEUR

1шт.

7

K9004679

BOLT

desc: BOULON

1шт.

8

K9004651

PIPE ASS'Y;LUB.OIL

desc: ENSEMBLE DE TUYAU

1шт.

9

2.313-00001

BOLT ASS'Y;JOINT

desc: BOULON

1шт.

10

2.120-00258

BOLT;JOINT

desc: . BOULON

1шт.

11

2.114-00889

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

1шт.

12

2.114-00889

SEAL;WASHER

desc: BAGUE D'ETANCHEITE

1шт.

13

K9004838

SEAL;WASHER

desc: BAGUE D'ETANCHEITE

2шт.

14

2.121-00092

NUT

desc: ECROU

1шт.

15

K9004650

BRACKET ASS'Y;FILTER

desc: SUPPORT

1шт.

17

K9004727

STUD

desc: . BOULON

1шт.

18

K9004750

GASKET

desc: JOINT

1шт.

19

K1025334

FILTER;OIL

desc: FILTRE

1шт.

20

2.120-00137

BOLT M8X20

desc: BOULON

3шт.

21

2.181-00353

PLUG;DRAIN

desc: BOUCHON

1шт.
