Запчасти Doosan Daewoo GEAR HOUSING ENGINE PARTS

1

K9004864

GEAR HOUSING ASS'Y

desc: CARTER DE PINGNON

1шт.

4

2181-1116D3

PLUG;SCREW PT3/8

desc: . BOUCHON

1шт.

5

K9004849

PLUG PT1/2

desc: . BOUCHON

1шт.

6

K9004667

SEAL;OIL

desc: . JOINT

1шт.

7

K9004646

PUMP COVER ASS'Y

desc: COUVERCLE DE POMPE

1шт.

8

K9004645

COVER;LUB.OIL PUMP

desc: . COUVERCLE

1шт.

9

K9004801

VALVE;RELIEF

desc: . VANNE

1шт.

10

K9004777

SPRING

desc: . RESSORT

1шт.

11

K9004689

PLUG

desc: . BOUCHON

1шт.

12

K9004631

FLANGE;GEAR CASE

desc: BRIDE

1шт.

13

K9004632

STUD

desc: BOULON

3шт.

14

D460483

CAP;FILLER

desc: COUVERCLE

1шт.

15

2.304-00001

COVER

desc: COUVERCLE

1шт.

16

K9004796

PIPE

desc: TUYAU

2шт.

17

K9004606

O-RING

desc: JOINT TORIQUE

4шт.

18

K9004647

ROTOR;INNER

desc: ROTOR INTERIEUR

1шт.

19

K9004648

ROTOR;OUTER

desc: ROTOR EXTERNE

1шт.

20

K9004649

SCREW

desc: VIS

7шт.

21

K9004676

O-RING

desc: JOINT TORIQUE

1шт.

22

K9004690

BOLT M8X85

desc: BOULON

3шт.

23

S8000320

O-RING

desc: JOINT TORIQUE

1шт.

24

2.120-00136

BOLT M8X16

desc: BOULON

4шт.

25

2.120-00136

BOLT M8X16

desc: BOULON

3шт.

26

2.120-00148

BOLT M8X55

desc: BOULON

12шт.

27

2.121-00267

NUT

desc: ECROU

3шт.

28

K9004671

COVER;BLIND

desc: COUVERCLE

1шт.

29

2.180-00355

O-RING

desc: JOINT TORIQUE

1шт.

30

2.120-00029

BOLT M6X16

desc: BOULON

2шт.

31

K9004868

GASKET;LIQUID

desc: JOINT

1шт.
