Запчасти Doosan Daewoo FUEL INJECTION VALVE ENGINE PARTS

1

K9004866

INJECTOR;FUEL

desc: INJECTEUR DE CARBURANT

3шт.

2

K9004713

NOZZLE;CMP

desc: . BEC

3шт.

5

2.121-00085

NUT

desc: . ECROU

3шт.

6

K9004661

HOLDER NOZZLE ASS'Y

desc: . BEC DE SUPPORT

3шт.

10

2.131-00258

SPRING;NOZZLE

desc: . RESSORT

3шт.

11

2.427-00019

SEAT;NOZZLE SPRING

desc: . SIEGE

3шт.

12

2.412-00266

PLATE;STOP

desc: . PLAQUE

3шт.

13

2.123-00088

PIN

desc: . GOUPILLE

6шт.

14

2.180-00611

SHIM;PACK

desc: . CALE

3шт.

26

K9004752

RETAINER;INJ PIPE

desc: ARRETOIR

2шт.

29

2.120-00050

BOLT M4X14

desc: . BOULON

4шт.

31

K9004715

INJECTION PIPE

desc: PIPE D'INJECTION

1шт.

35

K9004716

INJECTION PIPE

desc: PIPE D'INJECTION

1шт.

39

K9004717

INJECTION PIPE

desc: PIPE D'INJECTION

1шт.

44

K9004662

RETURN PIPE ASS'Y

desc: PIPE DE RETOUR

1шт.

45

2.124-00086

CLAMP

desc: . BRIDE

2шт.

46

K9004663

PIPE;FUEL RETURN

desc: . TUYAU

1шт.

47

2.140-00105

PIPE;FUEL RETURN

desc: PIPE DE RETOUR DE CARBURANT

2шт.

48

2.124-00086

CLAMP

desc: . BRIDE

4шт.

50

K9004605

CAP

desc: CHAPEAU

1шт.

51

K9004677

CLAMP

desc: BRIDE

1шт.
