1
K9004865
INJECTION PUMP ASS'Y
desc: PIPE D'INJECTION
1шт.
4
K9004808
JOINT
desc: . JOINT
1шт.
33
K9004830
STOPPER
desc: . ARRET
1шт.
34
K9004828
O-RING
desc: . JOINT TORIQUE
1шт.
35
K9004828
O-RING
desc: . JOINT TORIQUE
1шт.
36
K9004827
DELIVERY VALVE ASS'Y
desc: . SOUPAPE DE MANOEUVRE
3шт.
44
K9004829
SPRING
desc: . RESSORT
3шт.
45
K9004832
HOLDER;DELIVERY
desc: . SUPPORT
3шт.
48
K9004817
JOINT;COOLING WATER
desc: . L'EAU DE REFROIDISSEMENT
1шт.
49
K9004833
PLUG
desc: . BOUCHON
1шт.
50
K9004656
BARREL;PLUG
desc: . BARIL DE PRISE
1шт.
51
K9004805
WASHER
desc: . RONDELLE
3шт.
52
K9004805
WASHER
desc: . RONDELLE
1шт.
53
K9004826
PLUG
desc: . BOUCHON
1шт.
54
K9004883
PLUG
desc: . BOUCHON
1шт.
55
K9004806
FILTER
desc: . FILTRE
1шт.
56
K9004657
TIMER;SET
desc: . TEMPORISATEUR
1шт.
57
-
TIMER;CMP
SC: D
1шт.
60
K9004821
O-RING
desc: .. JOINT TORIQUE
1шт.
61
K9004659
RING;BACKUP
desc: .. BAGUE
1шт.
62
K9004660
O-RING
desc: .. JOINT TORIQUE
1шт.
63
K9004852
PACKING
desc: .. EMBALLAGE
1шт.
64
K9004853
RING;BACKUP
desc: .. BAGUE
1шт.
65
K9004807
PACKING;HEAD
desc: . EMBALLAGE
1шт.
66
K9004818
SPRING;TIMER
desc: . RESSORT
1шт.
68
K9004819
ELEMENT;THERMO
desc: . ELEMENT
1шт.
69
K9004834
JOINT
desc: . JOINT
1шт.
70
K9004820
O-RING
desc: . JOINT TORIQUE
1шт.
71
K9004822
PACKING;TIMER
desc: . EMBALLAGE
1шт.
78
K9004654
KEY
desc: . CLE
1шт.
98
K9004831
PISTON
desc: . PISTON
1шт.
99
K9004809
DAMPER ASS'Y
desc: . AMORTISSEUR
1шт.
100
K9004835
PLUG
desc: . BOUCHON
1шт.
101
2.114-01090
SEAL;WASHER
desc: . BAGUE D'ETANCHEITE
1шт.
102
K9004841
SEAL;WASHER
desc: . BAGUE D'ETANCHEITE
1шт.
103
K9004850
PLUG
desc: . BOUCHON
1шт.
105
K9004810
FEED PUMP ASS'Y
desc: . POMPE D'ALIMENTATION
1шт.
106
K9004813
O-RING
desc: .. JOINT TORIQUE
1шт.
107
K9004811
O-RING
desc: . JOINT TORIQUE
1шт.
108
2.114-01090
SEAL;WASHER
desc: . BAGUE D'ETANCHEITE
2шт.
109
2.114-01090
SEAL;WASHER
desc: . BAGUE D'ETANCHEITE
2шт.
110
K9004841
SEAL;WASHER
desc: . BAGUE D'ETANCHEITE
2шт.
111
K9004843
WASHER;SPRING
desc: . RONDELLE ELASTIQUE
1шт.
112
K9004845
PIN;PARALLEL
desc: . GOUPILLE
2шт.
113
K9004846
PIN;SPRING
desc: . GOUPILLE
2шт.
114
2.120-00259
BOLT;JOINT
desc: . BOULON
1шт.
116
S8000070
O-RING
desc: . JOINT TORIQUE
1шт.
117
K9004812
O-RING
desc: . JOINT TORIQUE
1шт.
118
K9004851
O-RING
desc: . JOINT TORIQUE
1шт.
119
K9004852
PACKING
desc: . EMBALLAGE
1шт.
120
2.120-00039
BOLT M6X10
desc: . BOULON
1шт.
121
K9004823
BOLT
desc: . BOULON
4шт.
125
K9004857
BOLT M8X45
desc: . BOULON
4шт.
126
K9004859
NUT;LOCK
desc: . ECROU
1шт.
128
K9004802
JOINT
desc: . JOINT
1шт.
130
K9004655
BRACKET;PUMP
desc: SUPPORT
1шт.
131
2.120-00136
BOLT M8X16
desc: BOULON
1шт.
132
2.120-00137
BOLT M8X20
desc: BOULON
1шт.
