Запчасти Doosan Daewoo FUEL INJECTION PUMP ENGINE PARTS

1

K9004865

INJECTION PUMP ASS'Y

desc: PIPE D'INJECTION

1шт.

4

K9004808

JOINT

desc: . JOINT

1шт.

33

K9004830

STOPPER

desc: . ARRET

1шт.

34

K9004828

O-RING

desc: . JOINT TORIQUE

1шт.

35

K9004828

O-RING

desc: . JOINT TORIQUE

1шт.

36

K9004827

DELIVERY VALVE ASS'Y

desc: . SOUPAPE DE MANOEUVRE

3шт.

44

K9004829

SPRING

desc: . RESSORT

3шт.

45

K9004832

HOLDER;DELIVERY

desc: . SUPPORT

3шт.

48

K9004817

JOINT;COOLING WATER

desc: . L'EAU DE REFROIDISSEMENT

1шт.

49

K9004833

PLUG

desc: . BOUCHON

1шт.

50

K9004656

BARREL;PLUG

desc: . BARIL DE PRISE

1шт.

51

K9004805

WASHER

desc: . RONDELLE

3шт.

52

K9004805

WASHER

desc: . RONDELLE

1шт.

53

K9004826

PLUG

desc: . BOUCHON

1шт.

54

K9004883

PLUG

desc: . BOUCHON

1шт.

55

K9004806

FILTER

desc: . FILTRE

1шт.

56

K9004657

TIMER;SET

desc: . TEMPORISATEUR

1шт.

57

-

TIMER;CMP

SC: D

1шт.

60

K9004821

O-RING

desc: .. JOINT TORIQUE

1шт.

61

K9004659

RING;BACKUP

desc: .. BAGUE

1шт.

62

K9004660

O-RING

desc: .. JOINT TORIQUE

1шт.

63

K9004852

PACKING

desc: .. EMBALLAGE

1шт.

64

K9004853

RING;BACKUP

desc: .. BAGUE

1шт.

65

K9004807

PACKING;HEAD

desc: . EMBALLAGE

1шт.

66

K9004818

SPRING;TIMER

desc: . RESSORT

1шт.

68

K9004819

ELEMENT;THERMO

desc: . ELEMENT

1шт.

69

K9004834

JOINT

desc: . JOINT

1шт.

70

K9004820

O-RING

desc: . JOINT TORIQUE

1шт.

71

K9004822

PACKING;TIMER

desc: . EMBALLAGE

1шт.

78

K9004654

KEY

desc: . CLE

1шт.

98

K9004831

PISTON

desc: . PISTON

1шт.

99

K9004809

DAMPER ASS'Y

desc: . AMORTISSEUR

1шт.

100

K9004835

PLUG

desc: . BOUCHON

1шт.

101

2.114-01090

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

1шт.

102

K9004841

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

1шт.

103

K9004850

PLUG

desc: . BOUCHON

1шт.

105

K9004810

FEED PUMP ASS'Y

desc: . POMPE D'ALIMENTATION

1шт.

106

K9004813

O-RING

desc: .. JOINT TORIQUE

1шт.

107

K9004811

O-RING

desc: . JOINT TORIQUE

1шт.

108

2.114-01090

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

2шт.

109

2.114-01090

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

2шт.

110

K9004841

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

2шт.

111

K9004843

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

1шт.

112

K9004845

PIN;PARALLEL

desc: . GOUPILLE

2шт.

113

K9004846

PIN;SPRING

desc: . GOUPILLE

2шт.

114

2.120-00259

BOLT;JOINT

desc: . BOULON

1шт.

116

S8000070

O-RING

desc: . JOINT TORIQUE

1шт.

117

K9004812

O-RING

desc: . JOINT TORIQUE

1шт.

118

K9004851

O-RING

desc: . JOINT TORIQUE

1шт.

119

K9004852

PACKING

desc: . EMBALLAGE

1шт.

120

2.120-00039

BOLT M6X10

desc: . BOULON

1шт.

121

K9004823

BOLT

desc: . BOULON

4шт.

125

K9004857

BOLT M8X45

desc: . BOULON

4шт.

126

K9004859

NUT;LOCK

desc: . ECROU

1шт.

128

K9004802

JOINT

desc: . JOINT

1шт.

130

K9004655

BRACKET;PUMP

desc: SUPPORT

1шт.

131

2.120-00136

BOLT M8X16

desc: BOULON

1шт.

132

2.120-00137

BOLT M8X20

desc: BOULON

1шт.
