Запчасти Doosan Daewoo CRANKSHAFT & PISTON ENGINE PARTS

1

K9004705

CRANKSHAFT ASS'Y

desc: VILEBREQUIN

1шт.

2

S5701041

PIN;PARALLEL

desc: . GOUPILLE

1шт.

5

K9004640

GEAR;CRANKSHAFT

desc: . PIGNON

1шт.

6

2.113-00005

KEY

desc: . CLE

1шт.

8

2.113-00005

KEY

desc: CLE

1шт.

9

K9004772

PULLEY;CRANKSHAFT

desc: POULIE

1шт.

10

K9004799

WASHER

desc: RONDELLE

1шт.

11

2.120-00858

BOLT;PULLEY

desc: BOULON

1шт.

12

2.120-00225

BOLT;FLYWHEEL

desc: BOULON

6шт.

13

K9004733

FLYWEEL W/RING GEAR

desc: FLYWEEL

1шт.

15

K9004666

GEAR;RING

desc: . PIGNON

1шт.

16

K9004718

PISTON ASS'Y

desc: ENSEMBLE PISTON

3шт.

18

K9004719

RING;PISTON

desc: . BAGUE

3шт.

22

K9004755

PIN;PISTON

desc: GOUPILLE

3шт.

23

K9004844

RING

desc: CIRCLIP

6шт.

24

D465084

CONNECTING ROD ASS'Y

desc: BIELLE ASS'Y

3шт.

28

K9004726

BUSH;PISTON PIN

desc: . DOUILLE

3шт.

29

K9004674

BOLT;CONNECTING ROD

desc: . BOULON

6шт.

30

K9004746

METAL;CRANK

desc: . METAL

3шт.

32

K9004747

METAL;CRANK (0.25)

SC: US

3шт.

34

K9004720

PISTON;W/RING (0.25)

SC: OS

3шт.

36

K9004721

RING;SET (0.25)

SC: OS

3шт.
