Запчасти Doosan Daewoo TRAVEL PIPING - TRACK WIDTH 3M TRACK PARTS

-

K1006794B

TRAVEL PIPING

SC: D

-2шт.

1

DS2040436

HOSE

desc: TUYAU FLEXIBLE

1шт.

2

DS2040437

HOSE

desc: TUYAU FLEXIBLE

1шт.

3

DS2040437

HOSE

desc: TUYAU FLEXIBLE

1шт.

4

DS2040436

HOSE

desc: TUYAU FLEXIBLE

1шт.

5

S2215466

BOLT;SOCKET

desc: BOULON DE PLOT

32шт.

6

2180-1026D19

O-RING

desc: JOINT TORIQUE

8шт.

7

2181-9081

FLANGE;SPLIT

desc: BRIDE

16шт.

8

DS2055858

HOSE

desc: TUYAU FLEXIBLE

1шт.

9

DS2055858

HOSE

desc: TUYAU FLEXIBLE

1шт.

10

2181-1126D83

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

11

S8000181

O-RING

desc: JOINT TORIQUE

2шт.

12

DS2347032

TEE

desc: TE

1шт.

13

S8000231

O-RING

desc: JOINT TORIQUE

1шт.

14

DS2094069

HOSE

desc: TUYAU FLEXIBLE

1шт.

15

DS2094069

HOSE

desc: TUYAU FLEXIBLE

1шт.

16

DS2347025

TEE

desc: TE

1шт.

17

S8000141

O-RING

desc: JOINT TORIQUE

1шт.

18

2181-1126D14

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

19

S8000111

O-RING

desc: JOINT TORIQUE

2шт.

20

2160-4003

BUSHING;RUBBER

desc: GARNISSAGE CAOUTCHOUC

2шт.
