Запчасти Doosan Daewoo MAIN PIPING(4) - SWING BODY PARTS

-

K1002988C

MAIN PIPING

SC: D

-2шт.

8

423-00199

BLOCK;SPACER

desc: BLOC

1шт.

9

S2215466

BOLT;SOCKET

desc: BOULON DE PLOT

8шт.

10

S2212266

BOLT;SOCKET

desc: BOULON DE PLOT

4шт.

11

S2212466

BOLT;SOCKET

desc: BOULON DE PLOT

4шт.

16

2181-9083

FLANGE;SPLIT

desc: FLASQUE

1шт.

19

2181-9078

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

3шт.

23

2180-1026D19

O-RING

desc: JOINT TORIQUE

5шт.

31

2181-9084A

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

4шт.

59

DS2045274

HOSE

desc: TUYAU FLEXIBLE

1шт.

60

DS2045240

HOSE

desc: TUYAU FLEXIBLE

1шт.
