Запчасти Doosan Daewoo AIR CLEANER BODY PARTS

-

K1005074B

AIR CLEANER ASS'Y

SC: D

-2шт.

1

204-00066

AIR CLEANER

desc: ENSEMBLE FILTRE A AIR

1шт.

1A

474-00037

ELEMENT;INNER

desc: . ELEMENT

1шт.

1B

474-00038

ELEMENT;OUTER

desc: . ELEMENT

1шт.

1C

204-00069

COVER

desc: . COUVERCLE

1шт.

1D

204-00070

VALVE

desc: . VANNE

1шт.

2

2204-9032

PRE-CLEANER

SERIAL: 5001-5055

1шт.

2

K1017883

PRE-CLEANER

SERIAL: 5056

1шт.

3

K1006040

PIPE

desc: CONDUITE

1шт.

4

124-00297A

BAND;AIR CLEANER

desc: ATTACHE DE TUYAU

2шт.

5

DS0025015

BOLT;SET

desc: BOULON A 6 PANS

12шт.

6

K1005120

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

7

K1005119

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

8

K1005359

PIPE;AIR

desc: CONDUITE

1шт.

9

S8510143

CLAMP;HOSE

desc: COLLIER

2шт.

10

S8510118

CLAMP;HOSE

desc: COLLIER

1шт.

11

S8510168

CLAMP;HOSE

desc: COLLIER

1шт.

12

K1006047

COVER

desc: COUVERCLE

1шт.

13

K1000640

SUPPORT

desc: SUPPORT

1шт.

14

K1002915

PLATE;ANTI-SKID

desc: PLAQUE

1шт.

15

K1002478

PLATE;ANTI-SKID

desc: PLAQUE

1шт.

16

DS0025022

BOLT;SET

desc: BOULON A 6 PANS

23шт.

17

DS0025024

BOLT;SET

desc: BOULON A 6 PANS

4шт.
