Запчасти Doosan Daewoo TRAVEL MOTOR - ROTARY GROUP HYDRAULIC PARTS

-

K9004020

ROTARY GROUP

desc: GROUPE ROTATIF

1шт.

1

K9004030

CYLINDER BLOCK ASS'Y

desc: BLOC CYLINDRE

1шт.

1-1

-

BLOCK;CYLINDER

SC: D

1шт.

1-2

K9004036

PLATE;CONTROL

desc: . PLAQUE

1шт.

1-3

K9004037

PIN;CENTER

desc: . GOUPILLE

1шт.

1-4

K9004038

PISTON ASS'Y

desc: . PISTON DE LEVIER

7шт.

1-6

K9004039

SHIM

desc: . CALE

1шт.

1-6

K9004040

SHIM

desc: . CALE

1шт.

1-6

K9004041

SHIM

desc: . CALE

1шт.

1-7

K9004042

SPRING

desc: . RESSORT

1шт.

1-11

K9004034

PLATE

desc: . PLAQUE

1шт.

1-12

K9004035

BOLT

desc: . BOULON A 6 PANS

14шт.

2

K9004043

SHAFT;DRIVE

desc: ARBRE

1шт.

3

K9004044

PIECE;DISTANCE

desc: GUIDE

1шт.

6

K9004045

SHIM 3.1t

desc: CALE

1шт.

6

K9004047

SHIM 3.5t

desc: CALE

1шт.

6

K9004046

SHIM 3.45t

desc: CALE

1шт.

7

K9004048

RING;RETAINING

desc: ANNEAU DE SOUTIEN

1шт.

10

K9004031

BEARING;TAPER ROLLER

desc: ROULEMENT ROULEAUX

1шт.

11

K9004032

BEARING;TAPER ROLLER

desc: ROULEMENT ROULEAUX

1шт.
