Запчасти Doosan Daewoo MAIN PUMP - ROTARY GROUP HYDRAULIC PARTS

2

K9004207

ROTARY GROUP

desc: GROUPE ROTATIF

1шт.

2A

K9004208

ROTARY GROUP. HYDR. SECTION

desc: . GROUPE ROTATIF

1шт.

2Aa

K9004210

CYLINDER

desc: .. CYLINDRE

1шт.

2Ab

K9004202

PIN;CENTER

desc: .. BROCHE CENTRALE

1шт.

2Ac

K9004209

PISTON & PISTON RINGS

desc: .. PISTON & BAGUE

9шт.

2Ac1

-

PISTON

SC: D

1шт.

2Ac2

K9004219

RING;STEEL SEALING

desc: ... ANNEAU

1шт.

2Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

2Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

2Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

2Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

2Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

2Ae

K9004238

CUP SPRING

desc: .. RESSORT

4шт.

2Af

K9004211

PLATE;RETAINING

desc: .. PLAQUE

1шт.

2Ag

K9004228

SCREW;PAN HEAD

desc: .. VIS

18шт.

2B

K9004212

SHAFT WITH BEARING ASS'Y

desc: . AXE

1шт.

2Ba

K9004213

SHAFT;DRIVE

desc: .. AXE

1шт.

2Bb

K9004248

SHIM

SC: R

1шт.

2Bb

K9004248

SHIM

SC: R

1шт.

2Bb

K9004248

SHIM

SC: R

1шт.

2Bb

K9004248

SHIM

SC: R

1шт.

2Bb

K9004248

SHIM

SC: R

1шт.

2Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

2Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

2Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

2Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

2Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

2Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

2Bd

K9004232

RING;RETAINING

desc: .. ANNEAU DE SOUTIEN

1шт.

2Be

K9004237

BEARING;UNIT TAPERED-ROLLER

desc: .. PALIER

1шт.

2Bf

K9004236

BEARING;TAPERED-ROLLER

desc: .. PALIER

1шт.

2D

K9004214

LENS;CONTROL RIGHT-HAND

desc: . COMMANDEZ L'OBJECTIF DROIT

1шт.

3

K9004215

ROTARY GROUP

desc: GROUPE ROTATIF

1шт.

3A

K9004208

ROTARY GROUP. HYDR. SECTION

desc: . GROUPE ROTATIF

1шт.

3Aa

K9004210

CYLINDER

desc: .. CYLINDRE

1шт.

3Ab

K9004202

PIN;CENTER

desc: .. BROCHE CENTRALE

1шт.

3Ac

K9004209

PISTON & PISTON RINGS

desc: .. PISTON & BAGUE

9шт.

3Ac1

-

PISTON

SC: D

1шт.

3Ac2

K9004219

RING;STEEL SEALING

desc: ... ANNEAU

1шт.

3Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

3Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

3Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

3Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

3Ad

K9004239

COLLAR;SPRING

SC: R

1шт.

3Ae

K9004238

CUP SPRING

desc: .. RESSORT

4шт.

3Af

K9004211

PLATE;RETAINING

desc: .. PLAQUE

1шт.

3Ag

K9004228

SCREW;PAN HEAD

desc: .. VIS

18шт.

3B

K9004216

SHAFT WITH BEARING ASS'Y

desc: . AXE

1шт.

3Ba

K9004217

SHAFT;DRIVE

desc: . AXE

1шт.

3Bb

K9004248

SHIM

SC: R

1шт.

3Bb

K9004248

SHIM

SC: R

1шт.

3Bb

K9004248

SHIM

SC: R

1шт.

3Bb

K9004248

SHIM

SC: R

1шт.

3Bb

K9004248

SHIM

SC: R

1шт.

3Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

3Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

3Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

3Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

3Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

3Bc

K9004259

PLATE;BACK-UP

SC: R

1шт.

3Bd

K9004232

RING;RETAINING

desc: . RONDELLE DE RETENUE

1шт.

3Be

K9004237

BEARING;UNIT TAPERED-ROLLER

desc: . ROULEMENT

1шт.

3Bf

K9004236

BEARING;TAPERED-ROLLER

desc: . PALIER

1шт.

3D

K9004218

LENS;CONTROL LEFT-HAND

desc: . COMMANDEZ L'OBJECTIF DROIT

1шт.

4

K9004230

GEAR PUMP ASS'Y

desc: POMPE DE PIGNON

1шт.

4A

K9004260

PUMP;GEAR

desc: . POMPE DE PIGNON

1шт.

4B

2180-1217D82

O-RING

desc: . JOINT TORIQUE

1шт.

4C

2180-1217D16

O-RING

desc: . JOINT TORIQUE

1шт.

4D

S2210276

BOLT;SOCKET

desc: . BOULON

2шт.

4E

S2209071

BOLT;SOCKET

desc: . BOULON

2шт.

5

-

HOUSING;PUMP

SC: D

1шт.

7

K9004196

GEAR

desc: PIGNON

1шт.

8

K9004204

SHAFT;STUB

desc: ARBRE

1шт.

20

2.115-00303

RING;RETAINING

desc: ANNEAU DE SOUTIEN

1шт.

21

K9004253

RING;SHAFT SEAL

desc: BAGUE

1шт.

22

K9004235

SHIM

desc: ENTERTOISE

1шт.

23

2.120-00611

SCREW;LOCKING

desc: VIS

1шт.

24

2.120-00612

SCREW;LOCKING

desc: VIS

3шт.

25

K9004233

BEARING;PLAIN ROLLER

desc: PALIER

2шт.

27

2.405-00240

KEY;SHAFT

desc: CLEF

1шт.
