Запчасти Doosan Daewoo MAIN PIPING(4) - ARM. BUCKET BODY PARTS

-

K1015918B

MAIN PIPING

SC: D

-2шт.

1

DS2040521

HOSE

desc: TUYAU FLEXIBLE

1шт.

2

DS2040522

HOSE

desc: TUYAU FLEXIBLE

1шт.

3

DS2040523

HOSE

desc: TUYAU FLEXIBLE

1шт.

4

DS2040576

HOSE

desc: TUYAU FLEXIBLE

1шт.

5

DS2038246

HOSE

desc: TUYAU FLEXIBLE

2шт.

6

DS2038245

HOSE

desc: TUYAU FLEXIBLE

2шт.

7

2180-1026D2

O-RING

desc: JOINT TORIQUE

9шт.

8

2180-1026D19

O-RING

desc: JOINT TORIQUE

3шт.

9

2181-9079

FLANGE

desc: BRIDE

18шт.

10

2181-9083

FLANGE;SPLIT

desc: BRIDE

6шт.

11

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

32шт.

12

S2212466

BOLT;SOCKET M10X1.5X40

desc: BOULON A 6 PANS CREUX

16шт.
