Запчасти Doosan Daewoo GEAR SHIFT SYSTEM - MISSION HYDRAULIC PARTS

10

K9005101

HOUSING

desc: BOITIER

1шт.

20

2.180-00081

GASKET

desc: JOINT

1шт.

32

1.131-00091

SPRING;COMPR

desc: RESSORT

1шт.

40

K9004150

PLUG

desc: BOUCHON

1шт.

43

2.180-00346

O-RING

desc: JOINT TORIQUE

1шт.

44

1.115-00050

RING;RETAINING

desc: ANNEAU DE SOUTIEN

1шт.

46

1.120-00172

PLUG

desc: BOUCHON

1шт.

48

2.180-01051

RING;SEALING

desc: BAGUE D'ETANCHEITE

1шт.

50

1.409-00084

PISTON

desc: PISTON

1шт.

52

1.420-00085

RELIEF VALVE

desc: VANNE

1шт.

52-1

2180-1216D14

O-RING

desc: . JOINT TORIQUE

1шт.

52-2

1.180-00148

O-RING

desc: . JOINT TORIQUE

1шт.

62

1.420-00043

VALVE;CHECK

desc: VANNE

1шт.

62-5

1.180-00139

O-RING

desc: . JOINT TORIQUE

1шт.

62-6

1.180-00140

O-RING

desc: . JOINT TORIQUE

1шт.

72

1.420-00044

VALVE;CHECK

desc: VANNE

1шт.

72-5

1.180-00139

O-RING

desc: . JOINT TORIQUE

1шт.

72-6

1.180-00140

O-RING

desc: . JOINT TORIQUE

1шт.

72-7

180-00408

O-RING

desc: . JOINT TORIQUE

1шт.

82

1.420-00045

VALVE;CHECK

desc: VANNE

1шт.

82-5

1.180-00139

O-RING

desc: JOINT TORIQUE

1шт.

82-6

1.180-00140

O-RING

desc: JOINT TORIQUE

1шт.

92

1.109-00062

NEEDLE;SLEEVE

desc: AIGUILLE

1шт.

95

K9001661

SET;ROTOR

desc: JEU DE ROTORS

1шт.

110

1.471-00004

FILTER;SCREEN

desc: FILTRE

1шт.

130

1.148-00008

BALL

desc: BOULE

4шт.

140

1.131-00111

SPRING;COMPR

desc: RESSORT

3шт.

150

1.115-00049

RING;RETAINING

desc: ANNEAU DE SOUTIEN

1шт.

202

1.120-00139

SCREW

desc: VIS

3шт.

210

K9004083

GASKET

desc: JOINT

1шт.

224

1.430-00026

COVER

desc: COUVERCLE

1шт.

235

1.180-00130

O-RING

desc: JOINT TORIQUE

2шт.

242

1.120-00107

SCREW;CAP

desc: VIS

1шт.

245

1.114-00285

WASHER

desc: CALE

1шт.

254

1.120-00140

SCREW

desc: VIS

23шт.

259

1.114-00285

WASHER

desc: CALE

23шт.

262

1.120-00108

SCREW;CAP

desc: VIS

2шт.

272

1.114-00285

WASHER

desc: CALE

2шт.

341

1.120-00173

PLUG;SCREW

desc: BOUCHON A VIS

1шт.

342

1.180-00060

O-RING

desc: JOINT TORIQUE

1шт.

372

K9001662

SHAFT;PUMP

desc: ARBRE

1шт.

380

1.430-00069

COVER;PUMP

desc: COUVERCLE

1шт.

480

1.109-00020

BEARING;BALL

desc: A BILLES ROULEMENT

1шт.

500

1.115-00050

RING;RETAINING

desc: ANNEAU DE SOUTIEN

1шт.

551

2.181-00438

SOCKET

desc: CLE A DOUILLE

2шт.

552

1.180-00103

O-RING

desc: JOINT TORIQUE

2шт.

570

K9004095

NUT;UNION

desc: ECROU

2шт.

580

K9004090

BALL

desc: BOULE

2шт.
