Запчасти Doosan Daewoo MAIN PUMP - E.P.P.R VALVE HYDRAULIC PARTS

1

2.430-00205

COVER

desc: COUVERCLE

1шт.

1A

2.430-00206

COVER

desc: . COUVERCLE

1шт.

1B

2.180-01199

O-RING

desc: . JOINT TORIQUE

1шт.

1C

2.120-00832

BOLT;SOCKET

desc: . BOULON

4шт.

2

K9001906

PORT PLATE WITH VALVES

desc: PLAQUE

1шт.

2A

-

PLATE;PORT

SC: D

1шт.

2B

2.409-00216

PISTON;VALVE

desc: . PISTON

1шт.

2C

2.131-00417

SPRING;PRESSURE

desc: . RESSORT

1шт.

2D

2.120-00617

PLUG

desc: . BOUCHON

1шт.

2E

2.114-00877

WASHER

desc: . RONDELLE

1шт.

2F

S2209361

SCREW;SOCKET-HEAD

desc: . VIS

2шт.

2G

2.180-01180

O-RING

desc: . JOINT TORIQUE

2шт.

2H

2.180-01182

O-RING

desc: . JOINT TORIQUE

1шт.

2I

K9001933

VALVE

desc: . VANNE

1шт.

2J

2.123-00138

PIN;DOUBLE BREAK-OFF

desc: . BROUCHE

1шт.
