Запчасти Doosan Daewoo BUCKET ASSY - 0.38§© (30") - SIDE PIN OPTION PARTS

-

K1013144

BUCKET ASS'Y-0.38§©

desc: GODET

1шт.

1

K1013145

BUCKET ASS'Y

SC: D

1шт.

1-1

K1013146

BUCKET;WELD

desc: . GODET

1шт.

1-1A

2713-1222A

ADAPTER;TOOTH

desc: .. DENT DE ADAPTEUR

4шт.

1-2

713-00022

POINT;TOOTH

desc: . DENT

4шт.

1-3

2705-1022

PIN;LOCKING

desc: . GOUPILLE

4шт.

1-4

2114-1859

WASHER;LOCKING

desc: . RONDELLE

4шт.

2

2713-1228A

CUTTER;SIDE(R.H)

desc: COIN DE GODET DROIT

1шт.

3

2713-1229A

CUTTER;SIDE(L.H)

desc: COIN DE GODET DROIT

1шт.

4

S0574761

BOLT

desc: BOULON

8шт.

5

S4013333

NUT

desc: ECROU

8шт.

6

2114-1831A

WASHER;HARD

desc: RONDELLE

8шт.
