Запчасти Doosan Daewoo TRAVEL MOTOR - ROTARY GROUP HYDRAULIC PARTS

-

K9001771

ROTARY GROUP

desc: GROUPE ROTATIF

1шт.

1

K9001777

CYLINDER BLOCK ASS'Y

desc: ENSEMBLE DE BLOC CYLINDRE

1шт.

1-1

K9001778

BLOCK;CYLINDER

SC: D

1шт.

1-2

K9001779

PLATE;CONTROL

desc: . PLAQUE

1шт.

1-3

K9001780

PIN;CENTER

desc: . GOUPILLE

1шт.

1-4

K9001781

PISTON ASS'Y

desc: . ENSEMBLE PISTON

1шт.

1-6

K9001782

SHIM 3.3t

desc: . CALE

1шт.

1-6

K9001783

SHIM 3.4t

desc: . CALE

1шт.

1-6

K9001784

SHIM 3.5t

desc: . CALE

1шт.

1-7

K9001785

SPRING

desc: . RESSORT

1шт.

1-11

K9001786

PLATE

desc: . PLAQUE

1шт.

1-12

K9004228

BOLT

desc: . BOULON

14шт.

2

K9001788

SHAFT;DRIVE

desc: ARBRE MOTEUR

1шт.

3

K9001789

PIECE;DISTANCE

desc: GUIDE

1шт.

6

K9001790

SHIM 3.1t

desc: CALE

1шт.

6

K9001816

SHIM 3.5t

desc: CALE

1шт.

6

K9001817

SHIM 3.45t

desc: CALE

1шт.

7

S6510650

RING;RETAINING

desc: BAGUE

1шт.

10

K9001818

BEARING;TAPER ROLLER

desc: ROULEMENT

1шт.

11

K9001819

BEARING;TAPER ROLLER

desc: ROULEMENT

1шт.
