Запчасти Doosan Daewoo OUTPUT - FRONT AXLE HYDRAULIC PARTS

10

K9001529

SEAL;SHAFT

desc: BAGUE ENTRET

2шт.

30

1.109-00093

BEARING;ROLLER

desc: ROULEMENT

2шт.

40

K9001530

BEARING;ROLLER

desc: ROULEMENT

2шт.

80

K9001531

HUB

desc: MOYEU

2шт.

90

1.180-00136

O-RING

desc: JOINT TORIQUE

2шт.

120

K9001532

CARRIER;DISC

desc: PORTE DISQUES

2шт.

130

K9001533

O-RING

desc: JOINT TORIQUE

4шт.

135

K9001534

O-RING

desc: JOINT TORIQUE

2шт.

160

K9001535

RING;GEAR

desc: BAGUE

2шт.

200

K9001536

PISTON

desc: PISTON

2шт.

205

K9001537

PIN;CYLINDRICAL

desc: GOUPILLE

6шт.

210

1.180-00371

U-RING

desc: BAGUE DE U

2шт.

214

1.115-00113

RING;SUPPORT

desc: BAGUE DE SOUTIEN

2шт.

230

K9001538

U-RING

desc: BAGUE DE U

2шт.

232

K9001539

RING;SUPPORT

desc: BAGUE DE SOUTIEN

2шт.

238

1.131-00110

SPRING;COMPR

desc: RESSORT

12шт.

239

K9001540

SPRING;COMPR

desc: RESSORT

12шт.

256

1.120-00148

SCREW

desc: VIS

12шт.

258

1.425-00019

SLEEVE;SPRING

desc: MANCHON

12шт.

270

K9001541

DISC;O.CLUTCH

desc: DISQUE

16шт.

280

K9001542

DISC;I.CLUTCH S=2.0

desc: DISQUE

16шт.

280

K9001543

DISC;I.CLUTCH S=2.5

desc: DISQUE

16шт.

280

K9001544

DISC;I.CLUTCH S=3.0

desc: DISQUE

16шт.

320

1.114-00517

WASHER;THRUST S=1.5

SC: R

2шт.

320

1.114-00519

WASHER;THRUST S=2.0

SC: R

2шт.

320

1.114-00521

WASHER;THRUST S=2.5

SC: R

2шт.

320

1.114-00523

WASHER;THRUST S=3.0

SC: R

2шт.

320

1.114-00518

WASHER;THRUST S=1.7

SC: R

2шт.

320

1.114-00520

WASHER;THRUST S=2.2

SC: R

2шт.

320

1.114-00522

WASHER;THRUST S=2.7

SC: R

2шт.

390

K9001545

CARRIER ASS'Y;PLANET

desc: PORTEUR

2шт.

390-1

K9001546

CARRIER;PLANET

SC: D

1шт.

390-2

K9001547

GEAR;PLANET

desc: . PIGNON

3шт.

390-3

1.109-00089

BEARING;ROLLER

desc: . ROULEMENT

3шт.

390-4

1.115-00178

RING

desc: . BAGUE

6шт.

390-5

1.115-00038

RING;RETAINING

desc: . BAGUE

3шт.

501

K9001478

PLUG;SCREW

desc: BOUCHON

2шт.

502

1.180-00135

O-RING

desc: JOINT TORIQUE

4шт.

510

1.120-00109

SCREW;CAP

desc: VIS

4шт.

630

1.120-00103

SCREW;CAP

desc: VIS

2шт.

540

K9001548

BOLT;WHEEL

desc: BOULON

20шт.
