Запчасти Doosan Daewoo WATER PUMP ASSY ENGINE PARTS

1

K9003050

GASKET;CONNECTION

desc: JOINT

1шт.

2

K9003062

SCREW;CAP

desc: VIS

3шт.

3

-

CONNECTION;WATER TRANSFER

SC: D

1шт.

4

K9003284

CONNECTION;WATER TRANSFER

desc: CONNECTEUR

1шт.

5

K9003309

SEAL;O-RING

desc: JOINT

1шт.

6

K9003248

WATER PUMP ASS'Y

desc: POMPE D'CEAU

1шт.

7

K9002321

PLUG;PIPE

desc: . BOUCHON

1шт.

8

K9002322

PLUG;PIPE

desc: . BOUCHON

1шт.

9

K9003008

PLUG;PIPE

desc: . BOUCHON

1шт.

10

K9003069

PLUG;THREADED

desc: . BOUCHON

2шт.

11

K9003070

SEAL;O-RING

desc: .. JOINT

1шт.

12

K9003074

PLUG;THREADED

SC: D

1шт.

13

K9003082

NIPPLE;COUPLING

desc: . GRAISSEUR

1шт.

14

K9003070

SEAL;O-RING

desc: .. JOINT

1шт.

15

K9003083

NIPPLE;COUPLING

desc: .. GRAISSEUR

1шт.

16

-

BEARING;BALL

SC: K

1шт.

17

K9002987

RING;RETAINING

SC: K

1шт.

18

K9003027

SEAL;OIL

SC: K

1шт.

19

K9003065

IMPELLER;WATER PUMP

SC: K

1шт.

20

K9003071

GEAR;WATER PUMP

desc: . PIGNON

1шт.

21

K9003106

RING;RETAINING

SC: K

1шт.

22

K9003129

COVER;WATER PUMP

desc: . COUVERCLE

1шт.

23

K9003202

SCREW;CAP

desc: . VIS

3шт.

24

K9003213

SHAFT;WATER PUMP

desc: . VILEBREQUIN

1шт.

25

K9003279

SEAL;O-RING

SC: K

1шт.

26

K9003294

BODY;WATER PUMP

desc: . ENSEMBLE POMPE A EAU

1шт.

27

K9003372

SEAL;WATER PUMP

SC: K

1шт.

28

K9003296

SEAL;O-RING

SC: K

1шт.

29

K9002371

SCREW;HEX FLANGE HEAD CAP

desc: VIS

2шт.

30

K9003085

COVER;PROTECTIVE

desc: COUVERCLE

1шт.

*

K9003399

KIT;WATER PUMP REPAIR

desc: ENSEMBLE POMPE A EAU

1шт.
