Запчасти Doosan Daewoo OIL COOLER & FILTER ENGINE PARTS

1

K9002978

SEAL;O-RING

desc: JOINT

2шт.

2

K9003062

SCREW;CAP

desc: VIS

4шт.

3

K9003089

PLUG;THREADED

desc: BOUCHON

1шт.

4

-

PLUG;THREADED

SC: D

1шт.

5

K9002326

SEAL;O-RING

desc: JOINT

1шт.

6

K9003135

ADAPTER;O-RING

desc: ADAPTEUR

2шт.

7

K9003138

SEAL;RECTANGULAR RING

desc: JOINT

2шт.

8

K9003161

RETAINER;CONNECTION

desc: ARRETOIR

1шт.

9

K9003164

HEAD;LUBE OIL FILTER

desc: TETE DE FILTRE

1шт.

10

K9003005

PLUG;PIPE

desc: . BOUCHON

1шт.

11

K9003069

PLUG;THREADED

desc: . BOUCHON

2шт.

12

K9003070

SEAL;O-RING

desc: .. JOINT

1шт.

13

K9003074

PLUG;THREADED

SC: D

1шт.

14

K9003075

PLUG;THREADED

desc: . BOUCHON

1шт.

15

-

PLUG;THREADED

SC: D

1шт.

16

K9003076

SEAL;O-RING

desc: .. JOINT

1шт.

17

K9003099

THERMOSTAT

desc: . THERMOSTAT

1шт.

18

K9003163

HEAD;LUBE OIL FILTER

desc: . TETE DE FILTRE

1шт.

19

K9003181

PLUG;THREADED

desc: . BOUCHON

1шт.

20

K9003091

SEAL;O-RING

desc: .. JOINT

1шт.

21

-

PLUG;THREADED

SC: D

1шт.

22

K9003270

PLUNGER;BYPASS VALVE

desc: . VANNE

1шт.

23

K9003273

RING;RETAINING

desc: . RONDELLE DE RETENUE

1шт.

24

K9003278

RING;RETAINING

desc: . RONDELLE DE RETENUE

1шт.

25

K9003292

PLUG;EXPANSION

desc: . BOUCHON

1шт.

26

K9003293

SPRING;COMPRESSION

desc: . RESSORT DE COMPRESSION

1шт.

27

K9003174

COOLER;OIL

desc: REFRIGERATION

1шт.

28

K9003230

SCREW;HEX FLANGE HEAD CAP

desc: VIS

6шт.

29

K9003272

GASKET;FILTER HEAD

desc: JOINT

1шт.

30

K9003304

SCREW;CAP

desc: VIS

2шт.

31

K9003311

GASKET;OIL COOLER SUPPORT

desc: JOINT

2шт.

32

K9003338

SCREW;HEX FLANGE HEAD CAP

desc: VIS

3шт.

33

474-00034A

FILTER;ENGINE OIL

desc: FILTRE

1шт.
