FUEL PUMP ASSY

Запчасти Doosan Daewoo FUEL PUMP ASSY ENGINE PARTS

9
23
10
29
22
7
24
27
8
26
18
1
11
25
20
21
15
19
17
16
17
14
15
17
16
13
15
12
16
25
28
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

K9003441

DAMPER;FUEL PUMP

desc: REGISTRE

1шт.

7

K9002973

SPRING;COMPRESSION

desc: . RESSORT DE COMPRESSION

1шт.

8

K9002982

SEAL;RECTANGULAR RING

desc: . JOINT

2шт.

9

K9003015

CAP;FUEL PUMP FILTER

desc: . CAP

1шт.

10

K9003030

SEAL;O-RING

desc: . JOINT

1шт.

11

K9003156

HUB;COUPLING

desc: . MOYEU

1шт.

12

K9003082

NIPPLE;COUPLING

desc: . GRAISSEUR

1шт.

13

K9003083

NIPPLE;COUPLING

SC: D

1шт.

14

K9003070

SEAL;O-RING

desc: .. JOINT

1шт.

15

K9003098

PLUG;THREADED

desc: . BOUCHON

4шт.

16

-

PLUG;THREADED

SC: D

1шт.

17

K9003097

SEAL;O-RING

desc: .. JOINT

1шт.

18

K9003114

RING;RETAINING

desc: . RONDELLE DE RETENUE

1шт.

19

K9003069

PLUG;THREADED

desc: . BOUCHON

1шт.

20

K9003074

PLUG;THREADED

SC: D

1шт.

21

K9003070

SEAL;O-RING

desc: .. JOINT

1шт.

22

K9003067

UNION;MALE

desc: . UNION

1шт.

23

-

UNION;MALE

SC: D

1шт.

24

K9003068

SEAL;O-RING

desc: .. JOINT

1шт.

25

K9003010

WASHER;PLAIN

desc: RONDELLE

8шт.

26

K9003084

NUT;REGULAR HEXAGON

desc: ECROU

4шт.

27

K9003087

SPIDER;JAW COUPLING

desc: ARBRE

1шт.

28

K9003102

SCREW;CAP

desc: VIS

4шт.

29

K9003118

GASKET;FUEL PUMP

desc: JOINT

1шт.
