Запчасти Doosan Daewoo FUEL FLOW SYSTEM ENGINE PARTS

1

K9002970

SPACER;MOUNTING

desc: ENTRETOISE

1шт.

2

K9003171

TUBE;FUEL SUPPLY

desc: TUBE

1шт.

3

K9003172

TUBE;FUEL DRAIN

desc: TUBE

1шт.

4

K9003223

ELBOW;TUBE CONNECTOR

desc: COUDE

1шт.

5

K9002390

NUT;HEXAGON

desc: ECROU

1шт.

6

K9003368

UNION;MALE

desc: UNION

2шт.

7

K9003375

HOSE;FLEXIBLE

desc: TUYAU FLEXIBLE

1шт.

8

K9002997

UNION;MALE

desc: UNION

1шт.

9

K9003076

SEAL;O-RING

desc: JOINT

1шт.

10

K9003388

HOSE;FLEXIBLE

desc: TUYAU FLEXIBLE

1шт.

11

K9002981

UNION;MALE

desc: UNION

1шт.

12

-

UNION;MALE

SC: D

1шт.

13

K9003076

SEAL;O-RING

desc: . JOINT

1шт.

14

K9003442

SCREW;CAP

desc: VIS

4шт.

15

K9002981

UNION;MALE

desc: UNION

1шт.

16

K9003076

SEAL;O-RING

desc: . JOINT

1шт.

17

-

UNION;MALE

SC: D

1шт.

18

K9003001

HEAD;FUEL FILTER

desc: TETE DE FILTRE D'ESSENCE

1шт.

19

K9003256

SCREW;CAPTIVE WASHER CAP

desc: VIS

2шт.

20

474-00033A

FILTER;FUEL

desc: ELEMENT

2шт.

21

K9003410

BRACKET;FILTER

desc: SUPPORT

1шт.
