Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

1

K9003165

HEAD;CYLINDER TLA

desc: CULASSE

1шт.

2

-

HEAD;CYLINDER

SC: D

1шт.

3

K9003003

PLUG;EXPANSION

desc: . BOUCHON

2шт.

4

K9002999

PLUG;EXPANSION

desc: . BOUCHON

2шт.

5

K9003004

PLUG;EXPANSION

desc: . BOUCHON

8шт.

6

K9003063

SEAL;O-RING

desc: . JOINT

6шт.

7

K9003236

SLEEVE;INJECTOR

desc: . MANCHON

6шт.

8

K9003153

INSERT;VALVE

desc: . INSRENT

24шт.

9

K9003195

GUIDE;VALVE

desc: . GUIDE-SOUPAPE

24шт.

10

K9003330

SPRING;VALVE

desc: . JOINT TORIQUE

24шт.

11

K9003246

KIT;INTAKE VALVE

desc: . VALVE DE PRISE

12шт.

12

-

VALVE;INTAKE

SC: D

12шт.

13

K9003186

COLLET;VALVE

desc: .. BAGUE

24шт.

14

K9003247

KIT;EXHAUST VALVE

desc: . SIEGE

12шт.

15

-

VALVE;EXHAUST

SC: D

12шт.

13

K9003186

COLLET;VALVE

desc: .. BAGUE

24шт.

17

K9003307

RETAINER;VALVE SPRING

desc: . ARRETOIR

24шт.

18

K9003121

GUIDE;VALVE SPRING

desc: . GUIDE-SOUPAPE

24шт.

19

K9002320

PLUG;PIPE

desc: . BOUCHON

16шт.

20

K9003276

PLUG;ORIFICE

desc: . BOUCHON

6шт.

21

K9003366

SEAL;VALVE STEM

desc: . JOINT

24шт.

22

K9003322

PLUG;EXPANSION

desc: . BOUCHON

2шт.

23

K9003086

SCREW;HEX FLANGE HEAD CAP

desc: VIS

29шт.

24

K9003436

SCREW;HEX FLANGE HEAD CAP

desc: VIS

3шт.

25

K9003374

GASKET;CYLINDER HEAD

desc: JOINT DE CULASSE

1шт.

26

K9003188

WASHER;SEALING

desc: RONDELLE

7шт.

27

K9003191

SCREW;HEX FLANGE HEAD CAP

desc: VIS

5шт.

28

K9003189

SCREW;HEX FLANGE HEAD CAP

desc: VIS

2шт.
