Запчасти Doosan Daewoo CRANK SHAFT & PISTON ENGINE PARTS

1

K9003130

CRANKSHAFT

desc: VILEBREQUIN

1шт.

2

K9003435

KEY;PLAIN WOODRUFF

desc: CLAVETTE WOODRUFF

1шт.

3

K9003144

GEAR;CRANKSHAFT

desc: PIGNON

1шт.

4

K9003398

OIL SEAL KIT

desc: BAGUE DE HUILE

1шт.

4

K9003249

OIL SEAL KIT

desc: BAGUE DE HUILE

1шт.

5

K9003280

SLEEVE;WEAR

desc: MANCHON

1шт.

6

K9003400

MAIN METAL KIT (STD)

desc: METAL

1шт.

6

K9003023

MAIN METAL KIT (0.25)

SC: US

1шт.

6

K9003024

MAIN METAL KIT (0.50)

SC: US

1шт.

7

K9003393

METAL;MAIN(UPPER)

desc: . PALIER

7шт.

8

K9003395

METAL;MAIN(LOWER)

desc: . PALIER

7шт.

9

K9003401

WASHER;THRUST(LOWER)

desc: . RONDELLE

2шт.

9

K9003402

WASHER;THRUST(LOWER-0.25)

SC: OS

2шт.

10

K9003394

WASHER;THRUST(UPPER)

desc: . RONDELLE

2шт.

10

K9003396

WASHER;THRUST(UPPER-0.25)

SC: OS

2шт.

15

K9003183

FLYWHEEL ASS'Y

desc: ENSEMBLE VOLANT

1шт.

16

K9003182

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

17

K9002969

GEAR;FLYWHEEL RING

desc: . PIGNON

1шт.

18

K9003416

SCREW;HEX FLANGE HEAD CAP

desc: VIS

8шт.

19

K9003177

DAMPER;VIBRATION

desc: AMORTISSEUR DE VIBRATIONS

1шт.

20

K9003214

PULLEY;CRANKSHAFT

desc: POULIE

1шт.

21

K9003295

PLATE;CLAMPING

desc: PLAQUE

1шт.

22

K9003269

SCREW;CAP

desc: VIS

5шт.

23

K9003411

PLATE;CLAMPING

desc: PLAQUE

1шт.

24

K9003426

PISTON KIT

desc: KIT PISTON

6шт.

25

K9004010

PISTON ASS'Y

desc: . PISTON

1шт.

26

-

TOP;PISTON

SC: D

1шт.

27

-

SKIRT;PISTON

SC: D

1шт.

28

K9003019

RING;RETAINING

desc: . RONDELLE DE RETENUE

2шт.

29

K9003423

PIN;PISTON

desc: . AXE DE PISTON

1шт.

30

K9003253

SET;PISTON RING

desc: . ANNEAU DE PISTON

6шт.

31

K9003160

RING;OIL PISTON

desc: .. BOUCHON

1шт.

32

K9003343

RING;COMPRESSION PISTON

desc: .. BOUCHON

1шт.

33

K9003315

RING;COMPRESSION PISTON

desc: .. BOUCHON

1шт.

34

K9003344

ROD;ENGINE CONNECTING

desc: BIELLE

6шт.

35

-

ROD;ENGINE CONNECTING

SC: D

6шт.

36

K9003341

BUSHING

desc: . MANCHON

1шт.

37

K9003048

DOWEL;RING

desc: . ANNEAU

2шт.

38

K9003049

SCREW; CAP

desc: . VIS

2шт.

39

K9003020

MAIN METAL CON-ROD (STD)

desc: METAL

12шт.

39

K9003021

MAIN METAL CON-ROD (0.25)

SC: US

12шт.

39

K9003022

MAIN METAL CON-ROD (0.50)

SC: US

12шт.
